Features Output frequency regulation: 0.5 Hz Input power factor: 0.63 Output operation voltage (min): 230 V Surge energy rating: 273 J Input frequency: 50/60 Hz Audible alarm modes: Low battery alarm Noise level: 40 dB Output power: 410 W Input operation voltage (min): 140 V Response time: 6 ms Audible alarm(s): Yes Output voltage regulation: 10% Input operation voltage (max): 300 V Output power capacity: 0.75 kVA UPS topology: Line-Interactive Waveform: Sine Surge protection: Yes Automatic Voltage Regulation (AVR): Yes Output frequency: 50/60 Hz Output operation voltage (max): 230 V
Design Cable length: 1.2 m LED indicators: Yes Product colour: Black International Protection (IP) code: IP20 Form factor: Compact
Operational conditions Storage temperature (T-T): -15 - 40 °C Operating temperature (T-T): 0 - 40 °C Operating altitude: 0 - 3000 m Operating relative humidity (H-H): 0 - 95%
Weight & dimensions Width: 120 mm Height: 160 mm Weight: 5.4 kg Depth: 355 mm
Packaging data Package height: 250 mm Package width: 197 mm
Packaging content Manual: Yes Cables included: Input power cable Management card included: No Certification: CB Meet EN62040-1 / CE / IEC-62040-1 / IEC-62040-2
Certificates Compliance certificates: RoHS
Ports & interfaces AC outlets quantity: 4 AC outlet(s) USB port type: USB Type-B SmartSlot: No Ethernet LAN (RJ-45) ports: 2 AC outlet types: Type F USB 2.0 ports quantity: 1 Power plug: Type F USB port: Yes SmartConnect port: No
Battery Typical backup time at half load: 8.5 min Battery technology: Sealed Lead Acid (VRLA) Typical backup time at full load: 1 min Battery life (max): 2 year(s) Battery recharge time: 6 h
Logistics data Harmonized System (HS) code: 85078000
