Features Input frequency: 50/60 Hz Waveform: Sine UPS topology: Line-Interactive Audible alarm modes: Low battery alarm Surge protection: Yes Output voltage regulation: 10% Output frequency: 50/60 Hz Output power capacity: 0.75 kVA Output operation voltage (min): 230 V Output frequency regulation: 0.5 Hz Input operation voltage (min): 140 V Output operation voltage (max): 230 V Input operation voltage (max): 300 V Surge energy rating: 273 J Input power factor: 0.63 Automatic Voltage Regulation (AVR): Yes Response time: 6 ms Audible alarm(s): Yes Output power: 410 W Noise level: 40 dB
Design Form factor: Compact International Protection (IP) code: IP20 LED indicators: Yes Cable length: 1.2 m Product colour: Black
Operational conditions Operating temperature (T-T): 0 - 40 °C Operating altitude: 0 - 3000 m Storage temperature (T-T): -15 - 40 °C Operating relative humidity (H-H): 0 - 95%
Weight & dimensions Height: 160 mm Depth: 355 mm Weight: 5.4 kg Width: 120 mm
Packaging data Package width: 197 mm Package height: 250 mm
Packaging content Management card included: No Cables included: Input power cable Manual: Yes Certification: CB Meet EN62040-1 / CE / IEC-62040-1 / IEC-62040-2
Certificates Compliance certificates: RoHS
Ports & interfaces USB port type: USB Type-B SmartSlot: No AC outlet types: C13 coupler SmartConnect port: No USB port: Yes USB 2.0 ports quantity: 1 Ethernet LAN (RJ-45) ports: 2 Power plug: C14 coupler AC outlets quantity: 4 AC outlet(s)
Battery Typical backup time at half load: 8.5 min Battery recharge time: 6 h Battery life (max): 2 year(s) Typical backup time at full load: 1 min Battery technology: Sealed Lead Acid (VRLA)
Logistics data Harmonized System (HS) code: 85078000
Safety warning Warnings: Use the appliance in well-ventilated areas to avoid overheating., Do not disassemble the unit housing, there may be a risk of electric shock., Keep away from sources of fire and water.
