Features
Surge protection features: Modem, Digital Subscriber Line (DSL), Telephone, Fax
Output frequency regulation: 47 - 63 Hz
Hold time (min): 6 ms
Input operation voltage (min): 160 V
Input operation voltage (max): 300 V
Power protection features: Overload
Hold time (max): 10 ms
Waveform: Sine
Output power: 300 W
Efficiency: 99%
UPS topology: Standby (Offline)
Output power capacity: 0.5 kVA
Audible alarm(s): Yes
Audible alarm modes: Low battery alarm, Overload alarm
Input frequency: 50/60 Hz
Surge protection: Yes
Noise level: 40 dB
Surge energy rating: 310 J
Design
Form factor: Tower
LED indicators: Battery replacement
Cable length: 1.83 m
Product colour: Beige
Operational conditions
Operating relative humidity (H-H): 0 - 95%
Storage relative humidity (H-H): 0 - 95%
Operating altitude: 0 - 3000 m
Operating temperature (T-T): 0 - 40 °C
Non-operating altitude: 0 - 15000 m
Storage temperature (T-T): -15 - 45 °C
Weight & dimensions
Height: 165 mm
Weight: 6.32 kg
Width: 91 mm
Depth: 284 mm
Bundled software: PowerChute Serial Edition
Packaging data
Package width: 241 mm
Warranty card: Yes
Package height: 178 mm
Packaging content
Cables included: Phone (RJ-11), USB cable
Quick installation guide: Yes
Management card included: No
Certification: C-tick, CE, EN 50091-1, EN 50091-2, GOST, VDE, REACH
Certificates
Compliance certificates: RoHS
Ports & interfaces
SmartConnect port: No
SmartSlot: No
AC outlets quantity: 4 AC outlet(s)
Power plug: C14 coupler
AC outlet types: C13 coupler
Number of output IEC jumpers: 2
USB port: Yes
Battery
Battery voltage: 12 V
Typical backup time at full load: 3.8 min
Battery life (max): 6 year(s)
Battery technology: Sealed Lead Acid (VRLA)
Battery recharge time: 8 h
Typical backup time at half load: 13.8 min
Automatic battery test: Yes
Battery capacity: 7 Ah, 83 VAh
Packaging content: Detachable 1.2m IEC power cord
Detachable 1.8 m IEC power cord
Other features
Filtering: Yes
Nominal output voltage: 230 V
Nominal input voltage: 230 V
Logistics data
Products per master (outer) case: 1 pc(s)
Harmonized System (HS) code: 85078000
Sustainability
Sustainability certificates: ENERGY STAR, Green Premium
