Features
UPS topology: Standby (Offline)
Efficiency: 98.9%
Output power capacity: 0.65 kVA
Input operation voltage (max): 286 V
Surge energy rating: 310 J
Input frequency: 50/60 Hz
Noise level: 45 dB
Audible alarm modes: Low battery alarm, Overload alarm
Hold time (max): 10 ms
Surge protection: Yes
Maximum current: 7 A
Surge protection features: Digital Subscriber Line (DSL), Telephone, Modem, Fax
Waveform: Sine
Audible alarm(s): Yes
Input operation voltage (min): 160 V
Output power: 400 W
Output frequency regulation: 47 - 63 Hz
Hold time (min): 6 ms
Design
LED indicators: Yes
Form factor: Tower
Cable length: 1.8 m
Product colour: Beige
Operational conditions
Non-operating altitude: 0 - 15240 m
Operating temperature (T-T): 0 - 40 °C
Storage relative humidity (H-H): 5 - 95%
Operating relative humidity (H-H): 5 - 95%
Operating altitude: 0 - 3048 m
Storage temperature (T-T): -15 - 45 °C
Weight & dimensions
Depth: 284 mm
Height: 165 mm
Weight: 6.03 kg
Width: 91 mm
Bundled software: PowerChute Serial Edition
Packaging data
Package width: 185 mm
Package height: 494 mm
Packaging content
Cables included: USB cable
Quick installation guide: Yes
Certification: A-tick, C-tick, CE, GOST, NEMKO
Certificates
Compliance certificates: RoHS
Ports & interfaces
AC outlet types: C13 coupler
Number of output IEC jumpers: 2
USB port: Yes
AC outlets quantity: 4 AC outlet(s)
Power plug: C14 coupler
Battery
Battery recharge time: 8 h
Typical backup time at half load: 14.7 min
Battery capacity: 9 Ah, 111 VAh
Battery voltage: 12 V
Typical backup time at full load: 4.7 min
Automatic battery test: Yes
Battery technology: Sealed Lead Acid (VRLA)
Battery life (max): 6 year(s)
Replacement battery cartridge: 1
Other features
Nominal output voltage: 230 V
Filtering: Yes
Nominal input voltage: 230 V
Logistics data
Products per master (outer) case: 1 pc(s)
Harmonized System (HS) code: 85078000
Sustainability
Sustainability certificates: ENERGY STAR, Green Premium
