Features Noise level: 45 dB Output power: 960 W Surge protection features: Network Waveform: Sine Audible alarm(s): Yes Input operation voltage (max): 294 V Input operation voltage (min): 176 V Output power capacity: 1.6 kVA UPS topology: Line-Interactive Maximum current: 10 A Surge energy rating: 509 J Input frequency: 50/60 Hz ECO mode: Yes Automatic Voltage Regulation (AVR): Yes Audible alarm modes: Alarm when on battery, Low battery alarm, Overload alarm Output frequency: 50/60 Hz Surge protection: Yes
Design Product colour: Black Cable length: 1.83 m LED indicators: Yes Form factor: Tower Cooling type: Passive Display type: LCD
Operational conditions Storage relative humidity (H-H): 0 - 95% Operating altitude: 0 - 3000 m Storage temperature (T-T): -15 - 45 °C Operating temperature (T-T): 0 - 40 °C Operating relative humidity (H-H): 0 - 95% Non-operating altitude: 0 - 15000 m
Weight & dimensions Weight: 10.9 kg Depth: 382 mm Height: 100 mm Width: 250 mm
Packaging data Package depth: 225 mm Package weight: 11.7 kg Package width: 485 mm Package height: 330 mm
Packaging content Manual: Yes Management card included: No Cables included: USB cable
Ports & interfaces USB 2.0 ports quantity: 1 AC outlets quantity: 8 AC outlet(s) Ethernet LAN (RJ-45) ports: 2 SmartConnect port: No Cabling technology: 10/100/1000Base-T(X) Power plug: C14 coupler AC outlet types: C13 coupler SmartSlot: No USB port: Yes
Battery Hot-swap battery: Yes Automatic battery test: Yes Battery recharge time: 16 h Battery life (max): 5 year(s) Battery technology: Sealed Lead Acid (VRLA) Cold start: Yes
Other features Nominal input voltage: 230 V Nominal output voltage: 230 V
Logistics data Harmonized System (HS) code: 85078000
