Features
Audible alarm(s): Yes
Surge protection features: Network, Digital Subscriber Line (DSL), Modem, Fax
Noise level: 45 dB
Output power: 540 W
Efficiency: 97.4%
Hold time (min): 8 ms
Hold time (max): 10 ms
Output power capacity: 0.9 kVA
UPS topology: Line-Interactive
Input operation voltage (max): 300 V
Input operation voltage (min): 156 V
Automatic Voltage Regulation (AVR): Yes
Input frequency: 50/60 Hz
Audible alarm modes: Low battery alarm, Overload alarm
Surge protection: Yes
Output frequency regulation: 50/60 Hz
Surge energy rating: 613 J
Design
Cable length: 1.83 m
Product colour: Black
Display type: LCD
Operational conditions
Storage temperature (T-T): -15 - 45 °C
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 0 - 95%
Storage relative humidity (H-H): 0 - 95%
Operating altitude: 0 - 3000 m
Non-operating altitude: 0 - 15000 m
Weight & dimensions
Depth: 250 mm
Width: 100 mm
Weight: 10.7 kg
Height: 382 mm
Bundled software: PowerChute Personal Edition
Packaging data
Package width: 225 mm
Package height: 487 mm
Warranty card: Yes
Packaging content
Manual: Yes
Cables included: Phone (RJ-11)
Certification: REACH, PEP, EOLI
Certificates
Compliance certificates: RoHS
Ports & interfaces
USB port: Yes
AC outlets quantity: 5 AC outlet(s)
AC outlet types: Type F
Number of type F outputs: 5
Battery
Battery technology: Sealed Lead Acid (VRLA)
Typical backup time at half load: 16.3 min
Battery recharge time: 8 h
Typical backup time at full load: 4.6 min
Cold start: Yes
Replacement battery cartridge: APCRBC123
Automatic battery test: Yes
Battery capacity: 157 VAh
Battery life (max): 5 year(s)
Other features
Nominal input voltage: 230 V
Nominal output voltage: 230 V
Logistics data
Harmonized System (HS) code: 85078000
Safety warning
Warnings: Use the appliance in well-ventilated areas to avoid overheating., Keep away from sources of fire and water., Do not disassemble the unit housing, there may be a risk of electric shock.
Sustainability
Sustainability certificates: Green Premium
