Features Input operation voltage (min): 170 V Response time: 6 ms Output operation voltage (min): 230 V Surge energy rating: 273 J Output power: 360 W Output power capacity: 0.7 kVA UPS topology: Line-Interactive Input frequency: 50/60 Hz Output voltage regulation: 10% Input power factor: 0.51 Output frequency regulation: 0.5 Hz Automatic Voltage Regulation (AVR): Yes Input operation voltage (max): 280 V Surge protection: Yes Waveform: Sine Output operation voltage (max): 230 V Noise level: 40 dB Audible alarm modes: Alarm when on battery, Battery replacement, Low battery alarm, Overload alarm Audible alarm(s): Yes Output frequency: 50/60 Hz
Design Form factor: Compact LED indicators: Yes International Protection (IP) code: IP20 Product colour: Black
Operational conditions Operating altitude: 0 - 3000 m Non-operating altitude: 0 - 3000 m Operating relative humidity (H-H): 0 - 95% Operating temperature (T-T): 0 - 40 °C Storage temperature (T-T): -15 - 40 °C
Weight & dimensions Weight: 4.5 kg Depth: 138 mm Height: 98 mm Width: 31 mm
Packaging data Package height: 142 mm Package depth: 346 mm Package weight: 4.5 kg Package width: 222 mm
Packaging content Cables included: Input power cable Manual: Yes Management card included: No
Ports & interfaces SmartSlot: No AC outlet types: C13 coupler SmartConnect port: No Power plug: C14 coupler AC outlets quantity: 4 AC outlet(s)
Battery Cold start: Yes Battery voltage: 12 V Battery life (max): 2 year(s) Battery technology: Sealed Lead Acid (VRLA) Battery capacity: 7 Ah Battery recharge time: 8 h
Logistics data Harmonized System (HS) code: 85078000
