Features Output power capacity: 1.6 kVA Input frequency: 50/60 Hz Input operation voltage (max): 300 V Input operation voltage (min): 140 V Noise level: 40 dB Output power: 900 W Audible alarm(s): Yes Response time: 6 ms Output operation voltage (max): 230 V UPS topology: Line-Interactive Output voltage regulation: 10% Output frequency regulation: 0.5 Hz Waveform: Sine Automatic Voltage Regulation (AVR): Yes Input power factor: 0.56 Surge energy rating: 273 J Output operation voltage (min): 230 V Audible alarm modes: Low battery alarm Output frequency: 50/60 Hz
Design LED indicators: Yes International Protection (IP) code: IP20 Form factor: Compact Cable length: 1.2 m Product colour: Black Built-in fan: Yes
Operational conditions Operating temperature (T-T): 0 - 40 °C Operating relative humidity (H-H): 0 - 95% Operating altitude: 0 - 3000 m Storage temperature (T-T): -15 - 40 °C
Weight & dimensions Depth: 390 mm Height: 190 mm Width: 140 mm Weight: 10.3 kg
Packaging data Package width: 390 mm Package height: 190 mm
Packaging content Cables included: Input power cable Manual: Yes Management card included: No Certification: CB Meet EN62040-1 / CE / IEC-62040-1 / IEC-62040-2
Certificates Compliance certificates: RoHS
Ports & interfaces AC outlets quantity: 6 AC outlet(s) USB 2.0 ports quantity: 1 Power plug: C13 coupler Ethernet LAN (RJ-45) ports: 2 USB port: Yes SmartConnect port: No AC outlet types: C13 coupler SmartSlot: No USB port type: USB Type-B
Battery Typical backup time at half load: 6.5 min Battery recharge time: 8 h Battery technology: Sealed Lead Acid (VRLA) Battery voltage: 24 V Typical backup time at full load: 1 min Battery capacity: 7 Ah Battery life (max): 2 year(s)
Logistics data Harmonized System (HS) code: 85078000
Safety warning Warnings: Keep away from sources of fire and water., Do not disassemble the unit housing, there may be a risk of electric shock., Use the appliance in well-ventilated areas to avoid overheating.
