Features
Output power: 1000 W
Web-based management: Yes
Noise level: 46 dB
Response time: 2 ms
Input operation voltage (min): 151 V
UPS topology: Line-Interactive
Input frequency: 50/60 Hz
Output operation voltage (min): 220 V
Surge energy rating: 459 J
Output frequency: 50/60 Hz
Audible alarm(s): Yes
Audible alarm modes: Battery replacement
Output voltage regulation: 5%
Output power capacity: 1.5 kVA
Waveform: Sine
Input operation voltage (max): 302 V
Emergency Power Off (EPO): O
Auto-restart: Yes
Output operation voltage (max): 240 V
Design
LED indicators: Yes
Form factor: Rackmount
Rack capacity: 2U
Product colour: Black
Display type: LCD
Operational conditions
Operating altitude: 0 - 3000 m
Storage relative humidity (H-H): 0 - 95%
Storage temperature (T-T): -15 - 45 °C
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 0 - 95%
Non-operating altitude: 0 - 15000 m
Weight & dimensions
Width: 432 mm
Weight: 28.6 kg
Depth: 457 mm
Height: 89 mm
Packaging data
Package height: 251 mm
Package width: 594 mm
Package depth: 603 mm
Package weight: 31.8 kg
Resource CD: Yes
Packaging content
Cables included: Input power cable, USB cable
Quick installation guide: Yes
Rack mount kit: Yes
Certification: CE, EAC, EN/IEC 62040-1, EN/IEC 62040-2, GS Mark, IRAM, RCM, VDE, WEEE
Certificates
Compliance certificates: RoHS
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
AC outlets quantity: 4 AC outlet(s)
USB 2.0 ports quantity: 1
Power plug: C14 coupler
AC outlet types: C13 coupler, C14 coupler
Battery
Battery technology: Sealed Lead Acid (VRLA)
Battery capacity: 432 Ah
Hot-swap battery: Yes
Automatic battery test: Yes
Cold start: Yes
Battery recharge time: 3 h
Other features
Output voltage: 230 V
Logistics data
Total carbon footprint (kg of CO2e): 1407.66
Products per pallet: 8 pc(s)
Harmonized System (HS) code: 85078000
Sustainability
Sustainability certificates: Green Premium
