Features
Waveform: Pure sine
Output operation voltage (min): 220 V
Output operation voltage (max): 240 V
Hold time (max): 2 ms
Input frequency: 50/60 Hz
Surge energy rating: 459 J
Noise level: 42 dB
Output power capacity: 0.75 kVA
UPS topology: Line-Interactive
Efficiency: 97.7%
Input operation voltage (min): 151 V
Audible alarm(s): Yes
Input operation voltage (max): 302 V
Automatic Voltage Regulation (AVR): Yes
Surge protection: Yes
Output power: 500 W
Auto-restart: Yes
Design
Form factor: Rackmount
LED indicators: Battery replacement
Product colour: Black
Rack capacity: 2U
Operational conditions
Operating relative humidity (H-H): 0 - 95%
Operating temperature (T-T): 0 - 40 °C
Storage relative humidity (H-H): 0 - 95%
Operating altitude: 0 - 3000 m
Non-operating altitude: 0 - 15000 m
Storage temperature (T-T): -15 - 45 °C
Weight & dimensions
Weight: 17.3 kg
Height: 89 mm
Depth: 406 mm
Width: 432 mm
Packaging data
Package width: 546 mm
Package height: 241 mm
Packaging content
Cables included: RS-232, USB cable
Quick installation guide: Yes
Rack mount kit: Yes
Certification: CE, CSA, EAC, EN/IEC 62040-1, EN/IEC 62040-2, RCM, TUV, UL 1778, VDE, REACH, PEP, EOLI
Certificates
Compliance certificates: RoHS
Ports & interfaces
Serial interface: Yes
Serial interface type: RJ-45
USB port: Yes
AC outlet types: C13 coupler
Number of output IEC jumpers: 2
Power plug: C14 coupler
AC outlets quantity: 4 AC outlet(s)
SmartSlot: Yes
Battery
Typical backup time at full load: 5.5 min
Automatic battery test: Yes
Battery recharge time: 3 h
Battery capacity: 168 VAh
Typical backup time at half load: 16 min
Hot-swap battery: Yes
Battery life (max): 5 year(s)
Battery technology: Sealed Lead Acid (VRLA)
Cold start: Yes
Logistics data
Harmonized System (HS) code: 85078000
Total carbon footprint (kg of CO2e): 821.3
Safety warning
Warnings: Use the appliance in well-ventilated areas to avoid overheating., Do not disassemble the unit housing, there may be a risk of electric shock., Keep away from sources of fire and water.
Sustainability
Sustainability certificates: Green Premium
