Features
Audible alarm(s): Yes
Input operation voltage (min): 170 V
Output power: 600 W
Output power capacity: 1 kVA
Surge protection: Yes
Noise level: 41 dB
Input operation voltage (max): 300 V
Output operation voltage (min): 220 V
Input frequency: 50/60 Hz
Output operation voltage (max): 240 V
Audible alarm modes: Alarm when on battery, Low battery alarm, Overload alarm
Surge energy rating: 680 J
UPS topology: Line-Interactive
Output voltage Total Harmonic Distortion (THD): 5%
Automatic Voltage Regulation (AVR): Yes
Waveform: Sine
Output frequency: 50/60 Hz
Design
Cable length: 2.44 m
Rack capacity: 2U
Form factor: Rackmount
Product colour: Black
Display type: LCD
Operational conditions
Non-operating altitude: 0 - 15000 m
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -15 - 45 °C
Storage relative humidity (H-H): 0 - 95%
Operating altitude: 0 - 3000 m
Operating relative humidity (H-H): 0 - 95%
Weight & dimensions
Width: 432 mm
Height: 86 mm
Depth: 406 mm
Weight: 20.5 kg
Packaging data
Package height: 235 mm
Package width: 535 mm
Resource CD: Yes
Packaging content
Cables included: RJ-45, RS-232
Rack mount kit: Yes
Management card included: No
Certification: CSA, CSA C22.2 No. 107.1, FCC Part 15 Class B, ICES-003, UL 1778, REACH
Certificates
Compliance certificates: RoHS
Ports & interfaces
Power plug: C14 coupler
USB 2.0 ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
AC outlets quantity: 4 AC outlet(s)
USB port: Yes
AC outlet types: C13 coupler
Serial interface type: RS-232
Serial interface: Yes
SmartSlot: No
SmartConnect port: Yes
Battery
Battery recharge time: 3 h
Battery technology: Sealed Lead Acid (VRLA)
Number of batteries supported: 1
Replacement battery cartridge: APCRBC124
Battery life (max): 6 year(s)
Logistics data
Harmonized System (HS) code: 85078000
Total carbon footprint (kg of CO2e): 945.86
Safety warning
Warnings: Do not disassemble the unit housing, there may be a risk of electric shock., Keep away from sources of fire and water., Use the appliance in well-ventilated areas to avoid overheating.
Sustainability
Sustainability certificates: ENERGY STAR, Green Premium
