Features
Input operation voltage (min): 151 V
Audible alarm modes: Battery replacement
UPS topology: Line-Interactive
Waveform: Sine
Emergency Power Off (EPO): O
Auto-restart: Yes
Input operation voltage (max): 302 V
Output operation voltage (max): 240 V
Output operation voltage (min): 220 V
Surge energy rating: 375 J
Output frequency: 50/60 Hz
Output power capacity: 2.2 kVA
Audible alarm(s): Yes
Response time: 4 ms
Surge protection: Yes
Output power: 1980 W
Input frequency: 50/60 Hz
Noise level: 55 dB
Web-based management: Yes
Design
Display type: LCD
Form factor: Rackmount
LED indicators: Yes
Product colour: Black
Rack capacity: 2U
Operational conditions
Non-operating altitude: 0 - 15000 m
Operating relative humidity (H-H): 0 - 95%
Operating altitude: 0 - 3000 m
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -15 - 45 °C
Storage relative humidity (H-H): 0 - 95%
Weight & dimensions
Weight: 42.2 kg
Height: 86 mm
Depth: 683 mm
Width: 480 mm
Packaging data
Resource CD: Yes
Package height: 254 mm
Package depth: 980 mm
Package width: 600 mm
Package weight: 49.6 kg
Packaging content
Management card included: Yes
Rack mount kit: Yes
Cables included: Input power cable, USB cable
Quick installation guide: Yes
Certification: CE, EAC, EN/IEC 62040-1, EN/IEC 62040-2, GS Mark, IRAM, RCM, VDE, WEEE
Certificates
Compliance certificates: RoHS
Ports & interfaces
AC outlet types: C20 coupler
SmartSlot: Yes
SmartConnect port: No
AC outlets quantity: 9 AC outlet(s)
Power plug: C20 coupler
USB 2.0 ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
Battery
Cold start: Yes
Hot-swap battery: Yes
Automatic battery test: Yes
Battery capacity: 509 Ah
Battery technology: Sealed Lead Acid (VRLA)
Battery recharge time: 5 h
Other features
Output voltage: 230 V
Logistics data
Harmonized System (HS) code: 85078000
Products per pallet: 8 pc(s)
Total carbon footprint (kg of CO2e): 3327.3
Sustainability
Sustainability certificates: Green Premium
