Features Output power capacity: 1 kVA Audible alarm modes: Alarm when on battery, Battery replacement Input operation voltage (min): 220 V Output operation voltage (min): 50 V Output voltage Total Harmonic Distortion (THD): 2% Noise level: 50 dB Output frequency: 50/60 Hz Surge energy rating: 432 J Input frequency: 40/70 Hz Input operation voltage (max): 240 V UPS topology: Double-conversion (Online) Output power: 1000 W Emergency Power Off (EPO): Yes Waveform: Sine Crest factor: 3:1 Audible alarm(s): Yes ECO mode: Yes Output operation voltage (max): 240 V Auto-restart: Yes
Design Rack capacity: 2U LED indicators: Yes International Protection (IP) code: IP20 Cable length: 1.8 m Display type: LCD Product colour: Black Form factor: Rackmount/Tower Cooling type: Active Built-in fan: Yes
Operational conditions Operating temperature (T-T): 0 - 40 °C Operating altitude: 0 - 3048 m Storage temperature (T-T): -20 - 50 °C Operating relative humidity (H-H): 0 - 95% Non-operating altitude: 0 - 15240 m
Weight & dimensions Battery width: 59.4 cm Battery depth: 74.9 cm Height: 432 mm Battery height: 24.6 cm Width: 85 mm Weight: 20.5 kg Depth: 505 mm Battery weight: 29.6 kg
Packaging content Cables included: USB cable Quick installation guide: Yes Management card included: No Certification: CE, EAC
Certificates Compliance certificates: CE
Ports & interfaces USB port: Yes AC outlet types: C13 coupler Serial ports quantity: 1 Power plug: C14 coupler Serial interface type: RJ-45 AC outlets quantity: 12 AC outlet(s) SmartSlot: Yes Serial interface: Yes SmartConnect port: No
Battery Typical backup time at half load: 21 min Hot-swap battery: Yes Battery technology: Sealed Lead Acid (VRLA) Battery voltage: 48 V Cold start: Yes Typical backup time at full load: 8 min Automatic battery test: Yes Battery recharge time: 3 h Battery life (max): 5 year(s)
Other features Nominal input voltage: 230 V Nominal output voltage: 230 V
Logistics data Harmonized System (HS) code: 85078000 Total carbon footprint (kg of CO2e): 1839.69
Safety warning Warnings: Do not disassemble the unit housing, there may be a risk of electric shock., Keep away from sources of fire and water., Use the appliance in well-ventilated areas to avoid overheating.
Sustainability Sustainability certificates: Green Premium Sustainability compliance: Yes
