Features
Output power: 2700 W
Audible alarm(s): Yes
Emergency Power Off (EPO): Yes
Efficiency: 92.4%
Auto-restart: Yes
Web-based management: Yes
Input operation voltage (max): 275 V
Surge protection: Yes
Surge energy rating: 340 J
Output frequency regulation: 50/60 Hz
Output power capacity: 3 kVA
Waveform: Sine
Output operation voltage (min): 220 V
Input frequency: 40/70 Hz
UPS topology: Double-conversion (Online)
Output operation voltage (max): 240 V
Noise level: 55 dB
Input operation voltage (min): 100 V
Design
Form factor: Tower
Display type: LCD
LED indicators: Yes
International Protection (IP) code: IP20
Product colour: Black
Cable length: 2.44 m
Operational conditions
Storage relative humidity (H-H): 0 - 95%
Operating altitude: 0 - 3000 m
Non-operating altitude: 0 - 15000 m
Operating relative humidity (H-H): 0 - 95%
Storage temperature (T-T): -15 - 45 °C
Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
Depth: 635 mm
Height: 432 mm
Weight: 31.3 kg
Width: 85 mm
Packaging data
Package height: 246 mm
Package depth: 871 mm
Package width: 599 mm
Package weight: 36.7 kg
Software CD: Yes
Packaging content
Management card included: No
Quick installation guide: Yes
Cables included: RS-232, USB cable
Certification: CE, CE Mark, CSA C22.2 No.107.3-05, EAC, EN/IEC 62040-1, EN/IEC 62040-2, FCC Part 15 Class A, RCM, UL 1778, VDE, REACH
Certificates
Compliance certificates: RoHS
Ports & interfaces
AC outlet types: C13 coupler, C19 coupler
SmartSlot: Yes
Power plug: C20 coupler
AC outlets quantity: 8 AC outlet(s)
USB port: Yes
Serial interface type: RJ-45
Serial interface: Yes
SmartConnect port: No
Battery
Battery technology: Sealed Lead Acid (VRLA)
Battery life (max): 5 year(s)
Automatic battery test: Yes
Hot-swap battery: Yes
Battery capacity: 505 VAh
Cold start: Yes
Typical backup time at half load: 11.8 min
Typical backup time at full load: 4 min
Battery recharge time: 3 h
Logistics data
Products per pallet: 6 pc(s)
Harmonized System (HS) code: 85078000
Total carbon footprint (kg of CO2e): 4961.68
Sustainability
Sustainability certificates: ENERGY STAR
