Features
Output power: 1980 W
Noise level: 55 dB
Audible alarm(s): Yes
Input frequency: 40 - 70 Hz
Emergency Power Off (EPO): Yes
Input operation voltage (max): 275 V
Output power capacity: 2.2 kVA
Waveform: Sine
Input operation voltage (min): 160 V
Crest factor: 3:1
UPS topology: Double-conversion (Online)
Surge energy rating: 340 J
Output voltage Total Harmonic Distortion (THD): 2%
Output operation voltage (min): 220 V
Output operation voltage (max): 240 V
Design
Rack capacity: 2U
LED indicators: Yes
Product colour: Black
Cable length: 2.44 m
International Protection (IP) code: IP20
Form factor: Rackmount
Display type: LCD
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating altitude: 0 - 3000 m
Storage temperature (T-T): -20 - 50 °C
Storage relative humidity (H-H): 0 - 95%
Operating relative humidity (H-H): 0 - 95%
Non-operating altitude: 0 - 15000 m
Weight & dimensions
Width: 432 mm
Depth: 584 mm
Height: 85 mm
Weight: 25 kg
Packaging data
Package weight: 34 kg
Package width: 599 mm
Package height: 246 mm
Package depth: 810 mm
Packaging content
Management card included: Yes
Certification: CE, CE Mark, EAC, EN/IEC 62040-1, EN/IEC 62040-2, RCM, VDE
Certificates
Compliance certificates: RoHS
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
AC outlets quantity: 12 AC outlet(s)
SmartConnect port: No
Number of output IEC jumpers: 2
AC outlet types: C13 coupler, C19 coupler
USB port: Yes
Serial interface: Yes
Serial interface type: RJ-45
SmartSlot: Yes
Battery
Battery technology: Sealed Lead Acid (VRLA)
Number of batteries supported: 1
Battery life (max): 5 year(s)
Battery capacity: 367 VAh
Battery recharge time: 3 h
Other features
Output voltage: 230 V
Logistics data
Total carbon footprint (kg of CO2e): 3656.79
Harmonized System (HS) code: 85078000
Sustainability
Sustainability certificates: Green Premium, ENERGY STAR
