Features
Audible alarm(s): Yes
Noise level: 55 dB
Power protection features: Overload
Output power: 2700 W
Input frequency: 40 - 70 Hz
Surge energy rating: 340 J
Output operation voltage (min): 220 V
Audible alarm modes: Battery replacement
Output operation voltage (max): 240 V
Output frequency: 50/60 Hz
Output power capacity: 3 kVA
Efficiency: 92%
Output voltage Total Harmonic Distortion (THD): 2%
UPS topology: Double-conversion (Online)
Waveform: Sine
Automatic Voltage Regulation (AVR): Yes
Input operation voltage (min): 100 V
Input operation voltage (max): 275 V
Surge protection: Yes
Crest factor: 3:1
Auto-restart: Yes
Emergency Power Off (EPO): Yes
Design
Form factor: Rackmount
LED indicators: Battery replacement
International Protection (IP) code: IP20
Rack capacity: 2U
Cable length: 2.44 m
Product colour: Black
Display type: LCD
Operational conditions
Operating altitude: 0 - 3000 m
Operating temperature (T-T): 0 - 40 °C
Storage relative humidity (H-H): 0 - 95%
Operating relative humidity (H-H): 0 - 95%
Storage temperature (T-T): -15 - 45 °C
Non-operating altitude: 0 - 15000 m
Weight & dimensions
Height: 85 mm
Width: 432 mm
Weight: 31.3 kg
Depth: 635 mm
Packaging data
Package width: 599 mm
Package height: 246 mm
Package weight: 39.3 kg
Package depth: 871 mm
Packaging content
Quick installation guide: Yes
Certification: CE, VDE, RCM, EAC, IEC/EN 62040-1, IEC/EN 62040-2, UL-1778, FCC 15 A, CSA
Certificates
Compliance certificates: RoHS
Ports & interfaces
Power plug: C20 coupler
USB port: Yes
AC outlet types: C19 coupler, C13 coupler
Serial interface: Yes
Serial interface type: RJ-45
SmartSlot: Yes
Battery
Typical backup time at full load: 4 min
Typical backup time at half load: 11.8 min
Battery technology: Sealed Lead Acid (VRLA)
Battery recharge time: 3 h
Automatic battery test: Yes
Cold start: Yes
Battery capacity: 505 VAh
Hot-swap battery: Yes
Battery life (max): 5 year(s)
Other features
Output voltage: 230 V
Logistics data
Harmonized System (HS) code: 85078000
Products per pallet: 6 pc(s)
Total carbon footprint (kg of CO2e): 4988.41
Sustainability
Sustainability certificates: Green Premium
