Features
Auto-restart: Yes
Surge energy rating: 480 J
Noise level: 55 dB
Output operation voltage (min): 220 V
Input operation voltage (min): 100 V
Input frequency: 40 - 70 Hz
Output power: 4500 W
UPS topology: Double-conversion (Online)
Output power capacity: 5 kVA
Output frequency regulation: 50/60 Hz
Crest factor: 3:1
Input operation voltage (max): 275 V
Efficiency: 94.1%
Audible alarm(s): Yes
Waveform: Sine
Output voltage Total Harmonic Distortion (THD): 3%
Output operation voltage (max): 240 V
Surge protection: Yes
Emergency Power Off (EPO): Yes
Design
Product colour: Black
Form factor: Rackmount
Display type: LCD
Rack capacity: 3U
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -15 - 45 °C
Storage relative humidity (H-H): 0 - 95%
Operating relative humidity (H-H): 0 - 95%
Operating altitude: 0 - 3000 m
Non-operating altitude: 0 - 15000 m
Weight & dimensions
Width: 432 mm
Depth: 719 mm
Weight: 54.4 kg
Height: 130 mm
Packaging data
Temperature sensor: Yes
Package width: 610 mm
Package depth: 960 mm
Package weight: 66.9 kg
Package height: 330 mm
Warranty card: Yes
Packaging content
Management card included: Yes
Quick installation guide: Yes
Rack mount kit: Yes
Certification: REACH, CE, CE Mark, EAC, EN/IEC 62040-1, EN/IEC 62040-2, IRAM, RCM, VDE
Certificates
Compliance certificates: RoHS
Ports & interfaces
Serial interface: Yes
SmartSlot: Yes
AC outlet types: C13 coupler, C19 coupler
Power plug: Hardwire
Serial interface type: RJ-45
AC outlets quantity: 10 AC outlet(s)
Number of output IEC jumpers: 2
SmartConnect port: No
USB port: Yes
Battery
Typical backup time at half load: 11.8 min
Replacement battery cartridge: APCRBC140
Battery life (max): 5 year(s)
Battery technology: Sealed Lead Acid (VRLA)
Typical backup time at full load: 4 min
Automatic battery test: Yes
Hot-swap battery: Yes
Cold start: Yes
Battery recharge time: 1.5 h
Battery capacity: 845 VAh
Logistics data
Products per pallet: 6 pc(s)
Total carbon footprint (kg of CO2e): 8408.59
Harmonized System (HS) code: 85078000
Sustainability
Sustainability certificates: ENERGY STAR
