Features
Response time: 6 ms
Noise level: 55 dB
Output power capacity: 2.2 kVA
Input frequency: 50/60 Hz
Audible alarm modes: Alarm when on battery, Low battery alarm
Waveform: Sine
UPS topology: Line-Interactive
Output voltage Total Harmonic Distortion (THD): 5%
Surge energy rating: 375 J
Audible alarm(s): Yes
Input operation voltage (min): 151 V
Output power: 1980 W
Input operation voltage (max): 302 V
Power protection features: Over voltage
Output operation voltage (min): 220 V
Output operation voltage (max): 240 V
Design
Rack capacity: 2U
Form factor: Rackmount
Product colour: Black
Cable length: 2 m
Display type: LCD
Operational conditions
Operating altitude: 0 - 3000 m
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -15 - 45 °C
Storage relative humidity (H-H): 0 - 95%
Operating relative humidity (H-H): 0 - 95%
Non-operating altitude: 0 - 15000 m
Weight & dimensions
Weight: 42.3 kg
Height: 86 mm
Width: 432 mm
Depth: 683 mm
Packaging data
Package width: 600 mm
Package height: 254 mm
Packaging content
Cables included: RS-232, USB cable
Management card included: No
Rack mount kit: Yes
Certification: CE, EAC, EN 60950, EN/IEC 62040-1, EN/IEC 62040-2, GS Mark, IRAM, RCM, VDE, WEEE
Certificates
Compliance certificates: RoHS
Ports & interfaces
USB 2.0 ports quantity: 1
AC outlets quantity: 9 AC outlet(s)
Ethernet LAN (RJ-45) ports: 1
Serial interface: Yes
SmartSlot: Yes
AC outlet types: IEC 60320
USB port type: USB Type-A
USB port: Yes
Serial interface type: RJ-45
SmartConnect port: Yes
Battery
Number of batteries supported: 1
Battery life (max): 5 year(s)
Battery technology: Sealed Lead Acid (VRLA)
Replacement battery cartridge: RBC43
Battery recharge time: 3 h
Logistics data
Harmonized System (HS) code: 85078000
Total carbon footprint (kg of CO2e): 3416.11
Safety warning
Warnings: Keep away from sources of fire and water., Use the appliance in well-ventilated areas to avoid overheating., Do not disassemble the unit housing, there may be a risk of electric shock.
Sustainability
Sustainability certificates: Green Premium
