Features
UPS topology: Line-Interactive
Noise level: 41 dB
Audible alarm modes: Alarm when on battery, Low battery alarm, Overload alarm
Output power capacity: 1 kVA
Waveform: Sine
Audible alarm(s): Yes
Input operation voltage (max): 302 V
Input frequency: 50/60 Hz
Temperature voltage compensation: Yes
Output voltage Total Harmonic Distortion (THD): 5%
Output operation voltage (min): 220 V
Output frequency: 50/60 Hz
Surge energy rating: 459 J
Automatic Voltage Regulation (AVR): Yes
Input operation voltage (min): 151 V
Response time: 10 ms
Surge protection: Yes
Auto-restart: Yes
Output power: 700 W
Output operation voltage (max): 240 V
Design
Form factor: Mini Tower
Display type: LCD
LED indicators: Yes
Product colour: Black
Operational conditions
Storage temperature (T-T): -15 - 45 °C
Operating relative humidity (H-H): 0 - 95%
Storage relative humidity (H-H): 0 - 95%
Operating altitude: 0 - 3000 m
Operating temperature (T-T): 0 - 40 °C
Non-operating altitude: 0 - 15000 m
Weight & dimensions
Width: 171 mm
Depth: 439 mm
Weight: 18.9 kg
Height: 219 mm
Packaging data
Package width: 328 mm
Package height: 376 mm
Packaging content
Cables included: RJ-45, USB cable
Quick installation guide: Yes
Certification: CE, CSA, EAC, EN/IEC 62040-1, EN/IEC 62040-2, RCM, UL 1778, VDE, REACH
Certificates
Compliance certificates: RoHS
Ports & interfaces
AC outlet types: IEC Jumpers, C13 coupler
Ethernet LAN (RJ-45) ports: 1
Serial ports quantity: 1
AC outlets quantity: 8 AC outlet(s)
Power plug: C14 coupler
USB port: Yes
Serial interface: Yes
USB 2.0 ports quantity: 1
SmartSlot: Yes
USB port type: USB Type-A
Battery
Replacement battery cartridge: RBC6
Battery technology: Sealed Lead Acid (VRLA)
Battery life (max): 5 year(s)
Automatic battery test: Yes
Cold start: Yes
Hot-swap battery: Yes
Battery recharge time: 3 h
Logistics data
Total carbon footprint (kg of CO2e): 984.74
Harmonized System (HS) code: 85078000
Sustainability
Sustainability certificates: Green Premium
