Features Auto-restart: Yes Temperature voltage compensation: Yes Web-based management: Yes UPS topology: Line-Interactive Response time: 10 ms Surge energy rating: 459 J Output power capacity: 1 kVA Output voltage Total Harmonic Distortion (THD): 5% Noise level: 45 dB Output power: 700 W Input operation voltage (min): 151 V Waveform: Sine Output frequency: 50/60 Hz Surge protection: Yes Input frequency: 50/60 Hz Automatic Voltage Regulation (AVR): Yes Input operation voltage (max): 302 V Output operation voltage (max): 240 V Output operation voltage (min): 220 V
Design Rack capacity: 2U LED indicators: Yes Product colour: Black Form factor: Rackmount Display type: LCD
Operational conditions Operating altitude: 0 - 3000 m Storage relative humidity (H-H): 0 - 95% Operating temperature (T-T): 0 - 40 °C Storage temperature (T-T): -15 - 45 °C Operating relative humidity (H-H): 0 - 95% Non-operating altitude: 0 - 15000 m
Weight & dimensions Weight: 22.5 kg Width: 432 mm Depth: 477 mm Height: 86 mm
Packaging data Package weight: 31.4 kg Software CD: Yes Package depth: 603 mm Package width: 594 mm Resource CD: Yes Package height: 251 mm
Packaging content Management card included: No Rack mount kit: Yes Quick installation guide: Yes Cables included: RS-232, USB cable Certification: EAC, EN/IEC 62040-1, EN/IEC 62040-2, RCM, UL 1778, VDE, REACH
Certificates Compliance certificates: RoHS
Ports & interfaces SmartSlot: Yes Serial interface: Yes USB port type: USB Type-A Ethernet LAN (RJ-45) ports: 1 AC outlets quantity: 4 AC outlet(s) AC outlet types: C13 coupler USB port: Yes Serial interface type: RJ-45 SmartConnect port: Yes
Battery Cold start: Yes Battery life (max): 6 year(s) Battery technology: Sealed Lead Acid (VRLA) Automatic battery test: Yes Hot-swap battery: Yes Number of batteries supported: 1 Replacement battery cartridge: APCRBC132 Battery recharge time: 3 h
Logistics data Total carbon footprint (kg of CO2e): 1165.17 Products per pallet: 8 pc(s) Harmonized System (HS) code: 85078000
Sustainability Sustainability certificates: Green Premium
