Features
Output power: 1980 W
Noise level: 45 dB
Power protection features: Overload, Over voltage
Input frequency: 50/60 Hz
Auto-restart: Yes
Output operation voltage (min): 220 V
Output voltage Total Harmonic Distortion (THD): 5%
Surge energy rating: 365 J
Audible alarm(s): Yes
Output power capacity: 2.2 kVA
Waveform: Sine
Input operation voltage (max): 302 V
UPS topology: Line-Interactive
Input operation voltage (min): 151 V
Audible alarm modes: Alarm when on battery, Low battery alarm, Battery replacement
Emergency Power Off (EPO): Yes
Output operation voltage (max): 240 V
Response time: 6 ms
Design
Display type: LCD
LED indicators: Yes
Product colour: Black
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Storage relative humidity (H-H): 0 - 95%
Storage temperature (T-T): -15 - 45 °C
Operating relative humidity (H-H): 0 - 95%
Non-operating altitude: 0 - 15000 m
Operating altitude: 0 - 3000 m
Weight & dimensions
Width: 197 mm
Depth: 544 mm
Height: 435 mm
Weight: 48.8 kg
Packaging data
Package height: 699 mm
Package width: 381 mm
Package depth: 762 mm
Software CD: Yes
Package weight: 61.9 kg
Packaging content
Cables included: RS-232, USB cable
Certification: CE, CSA, EAC, EN/IEC 62040-1, EN/IEC 62040-2, RCM, VDE
Certificates
Compliance certificates: RoHS
Ports & interfaces
AC outlet types: IEC 60320
Serial interface: Yes
SmartSlot: Yes
USB port: Yes
Serial ports quantity: 1
USB port type: USB Type-A
USB 2.0 ports quantity: 1
AC outlets quantity: 9 AC outlet(s)
Ethernet LAN (RJ-45) ports: 1
Battery
Battery technology: Sealed Lead Acid (VRLA)
Battery life (max): 5 year(s)
Typical backup time at half load: 25 min
Typical backup time at full load: 8.7 min
Battery recharge time: 3 h
Logistics data
Harmonized System (HS) code: 85078000
Products per pallet: 9 pc(s)
Total carbon footprint (kg of CO2e): 3715.93
Sustainability
Sustainability certificates: Green Premium
