Features
Output operation voltage (max): 240 V
Input operation voltage (min): 151 V
Output power capacity: 3 kVA
Input operation voltage (max): 302 V
Output power: 2700 W
Noise level: 55 dB
Audible alarm modes: Battery replacement
Web-based management: Yes
Response time: 4 ms
Audible alarm(s): Yes
Emergency Power Off (EPO): O
Input frequency: 50/60 Hz
Output operation voltage (min): 220 V
Surge protection: Yes
UPS topology: Line-Interactive
Output frequency: 50/60 Hz
Surge energy rating: 320 J
Waveform: Sine
Auto-restart: Yes
Design
LED indicators: Yes
Product colour: Black
Display type: LCD
Form factor: Rackmount
Cable length: 2 m
Rack capacity: 2U
Operational conditions
Non-operating altitude: 0 - 15000 m
Operating altitude: 0 - 3000 m
Operating relative humidity (H-H): 0 - 95%
Storage temperature (T-T): -15 - 45 °C
Operating temperature (T-T): 0 - 40 °C
Storage relative humidity (H-H): 0 - 95%
Weight & dimensions
Width: 480 mm
Depth: 683 mm
Height: 86 mm
Weight: 44.2 kg
Packaging data
Package depth: 980 mm
Package weight: 51.6 kg
Package height: 254 mm
Package width: 600 mm
Resource CD: Yes
Packaging content
Quick installation guide: Yes
Cables included: Input power cable, USB cable
Rack mount kit: Yes
Management card included: Yes
Certification: CE, EAC, EN/IEC 62040-1, EN/IEC 62040-2, GS Mark, IRAM, RCM, VDE, WEEE
Certificates
Compliance certificates: RoHS
Ports & interfaces
AC outlet types: C20 coupler, C13 coupler, C19 coupler
USB 2.0 ports quantity: 1
Power plug: C20 coupler
AC outlets quantity: 9 AC outlet(s)
SmartConnect port: No
SmartSlot: Yes
Battery
Battery recharge time: 3 h
Hot-swap battery: Yes
Battery technology: Sealed Lead Acid (VRLA)
Cold start: Yes
Battery capacity: 547 Ah
Automatic battery test: Yes
Other features
Output voltage: 230 V
Logistics data
Harmonized System (HS) code: 85078000
Products per pallet: 8 pc(s)
Total carbon footprint (kg of CO2e): 2958.37
Sustainability
Sustainability certificates: Green Premium
