Features
Noise level: 40 dB
Output power: 500 W
Audible alarm(s): Yes
Input operation voltage (min): 151 V
Waveform: Sine
Input operation voltage (max): 302 V
Input frequency: 50/60 Hz
Surge energy rating: 540 J
UPS topology: Line-Interactive
Output operation voltage (min): 220 V
Automatic Voltage Regulation (AVR): Yes
Output operation voltage (max): 240 V
Efficiency: 98%
Output power capacity: 0.75 kVA
Auto-restart: Yes
Design
LED indicators: Status
Product colour: Black
Cable length: 1.83 m
Form factor: Tower
Display type: LCD
Operational conditions
Operating altitude: 0 - 3000 m
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 5 - 95%
Storage relative humidity (H-H): 0 - 95%
Storage temperature (T-T): -15 - 45 °C
Non-operating altitude: 0 - 15000 m
Weight & dimensions
Height: 157 mm
Depth: 358 mm
Width: 138 mm
Weight: 13.2 kg
Bundled software: Powershute Serial Edition
Packaging data
Package weight: 14.2 kg
Package depth: 499 mm
Package height: 301 mm
Package width: 278 mm
Packaging content
Cables included: USB cable
Manual: Yes
Quick installation guide: Yes
Management card included: No
Certification: CE, CSA, EAC, EN/IEC 62040-1, EN/IEC 62040-2, RCM, UL 1778, VDE, REACH, PEP, EOLI
Certificates
Compliance certificates: RoHS
Ports & interfaces
AC outlets quantity: 6 AC outlet(s)
Ethernet LAN (RJ-45) ports: 1
Number of output IEC jumpers: 2
USB port: Yes
Power plug: C14 coupler
SmartConnect port: Yes
AC outlet types: C13 coupler
SmartSlot: Yes
Battery
Battery technology: Sealed Lead Acid (VRLA)
Hot-swap battery: Yes
Automatic battery test: Yes
Typical backup time at half load: 15.8 min
Cold start: Yes
Typical backup time at full load: 4.6 min
Battery recharge time: 3 h
Battery life (max): 5 year(s)
Replacement battery cartridge: rbc48
Logistics data
Products per pallet: 24 pc(s)
Harmonized System (HS) code: 85078000
Total carbon footprint (kg of CO2e): 639.93
Sustainability
Sustainability certificates: Green Premium
