Features
Output frequency regulation: +/- 3 Hz
Output power capacity: 0.75 kVA
UPS topology: Line-Interactive
Output voltage regulation: 5%
Output frequency: 50/60 Hz
Output operation voltage (max): 240 V
Emergency Power Off (EPO): O
Surge protection: Yes
Input frequency: 50/60 Hz
Waveform: Sine
Surge energy rating: 459 J
Audible alarm modes: Battery replacement
Auto-restart: Yes
Input operation voltage (min): 151 V
Input operation voltage (max): 302 V
Output operation voltage (min): 220 V
Audible alarm(s): Yes
Output power: 500 W
Web-based management: Yes
Response time: 2 ms
Noise level: 46 dB
Design
Display type: LCD
Product colour: Black
LED indicators: Yes
Rack capacity: 2U
Form factor: Rackmount
Operational conditions
Non-operating altitude: 0 - 15000 m
Operating temperature (T-T): 0 - 40 °C
Operating altitude: 0 - 3000 m
Storage relative humidity (H-H): 0 - 95%
Storage temperature (T-T): -15 - 45 °C
Operating relative humidity (H-H): 0 - 95%
Weight & dimensions
Depth: 406 mm
Height: 89 mm
Weight: 17.2 kg
Width: 432 mm
Packaging data
Resource CD: Yes
Package depth: 584 mm
Package width: 546 mm
Package height: 241 mm
Package weight: 21.2 kg
Packaging content
Management card included: Yes
Rack mount kit: Yes
Quick installation guide: Yes
Cables included: Input power cable, USB cable
Certification: CE, EAC, EN/IEC 62040-1, EN/IEC 62040-2, GS Mark, IRAM, RCM, VDE, WEEE
Certificates
Compliance certificates: RoHS
Ports & interfaces
Power plug: C14 coupler
SmartSlot: Yes
AC outlet types: C14 coupler, C13 coupler
SmartConnect port: No
USB 2.0 ports quantity: 1
AC outlets quantity: 4 AC outlet(s)
Ethernet LAN (RJ-45) ports: 1
Battery
Cold start: Yes
Automatic battery test: Yes
Hot-swap battery: Yes
Battery recharge time: 3 h
Battery capacity: 168 Ah
Battery technology: Sealed Lead Acid (VRLA)
Other features
Output voltage: 230 V
Logistics data
Products per pallet: 16 pc(s)
Harmonized System (HS) code: 85078000
Total carbon footprint (kg of CO2e): 497.38
Safety warning
Warnings: Use the appliance in well-ventilated areas to avoid overheating., Keep away from sources of fire and water., Do not disassemble the unit housing, there may be a risk of electric shock.
Sustainability
Sustainability certificates: Green Premium
