Features
Output power capacity: 2.2 kVA
Noise level: 55 dB
Input frequency: 40/70 Hz
Web-based management: Yes
Output power: 1980 W
Audible alarm(s): Yes
UPS topology: Double-conversion (Online)
Efficiency: 92.2%
Input operation voltage (max): 275 V
Waveform: Sine
Auto-restart: Yes
Crest factor: 3:1
Output operation voltage (min): 220 V
Surge energy rating: 340 J
Input operation voltage (min): 100 V
Surge protection: Yes
Emergency Power Off (EPO): Yes
Output frequency regulation: 50/60 Hz
Output operation voltage (max): 240 V
Design
LED indicators: Yes
Cable length: 2.44 m
Rack capacity: 2U
International Protection (IP) code: IP20
Form factor: Rackmount/Tower
Product colour: Black
Display type: LCD
Operational conditions
Storage relative humidity (H-H): 0 - 95%
Storage temperature (T-T): -20 - 50 °C
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 0 - 95%
Operating altitude: 0 - 3000 m
Non-operating altitude: 0 - 15000 m
Weight & dimensions
Depth: 584 mm
Height: 85 mm
Width: 432 mm
Weight: 25 kg
Packaging data
Package weight: 34 kg
Package width: 599 mm
Package depth: 810 mm
Package height: 246 mm
Bracket: Yes
Software CD: Yes
Packaging content
Cables included: USB cable
Quick installation guide: Yes
Rack mount kit: Yes
Certification: CE, CE Mark, EAC, EN/IEC 62040-1, EN/IEC 62040-2, RCM, VDE, REACH
Certificates
Compliance certificates: RoHS
Ports & interfaces
USB port: Yes
AC outlets quantity: 10 AC outlet(s)
Power plug: C20 coupler
Number of output IEC jumpers: 2
AC outlet types: C19 coupler, C13 coupler
Serial interface type: RJ-45
SmartSlot: Yes
Serial interface: Yes
Battery
Battery recharge time: 3 h
Typical backup time at half load: 11.6 min
Battery technology: Sealed Lead Acid (VRLA)
Typical backup time at full load: 3.9 min
Automatic battery test: Yes
Number of batteries supported: 1
Hot-swap battery: Yes
Battery life (max): 5 year(s)
Cold start: Yes
Battery capacity: 367 VAh
Other features
Nominal input voltage: 230 V
Nominal output voltage: 230 V
Logistics data
Total carbon footprint (kg of CO2e): 3656.4
Harmonized System (HS) code: 85078000
Products per pallet: 12 pc(s)
Sustainability
Sustainability certificates: Green Premium, ENERGY STAR
