Features
Efficiency: 94.1%
Output frequency regulation: 50/60 Hz
UPS topology: Double-conversion (Online)
Output power capacity: 5 kVA
Crest factor: 3:1
Audible alarm(s): Yes
Input operation voltage (max): 275 V
Input operation voltage (min): 100 V
Surge protection: Yes
Output operation voltage (max): 240 V
Auto-restart: Yes
Surge energy rating: 480 J
Input frequency: 40 - 70 Hz
Noise level: 55 dB
Emergency Power Off (EPO): Yes
Waveform: Sine
Output operation voltage (min): 220 V
Output power: 4500 W
Design
Display type: LCD
LED indicators: Status
International Protection (IP) code: IP20
Product colour: Black
Operational conditions
Operating altitude: 0 - 3000 m
Storage relative humidity (H-H): 0 - 95%
Non-operating altitude: 0 - 15000 m
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 0 - 95%
Storage temperature (T-T): -15 - 45 °C
Weight & dimensions
Depth: 719 mm
Width: 130 mm
Weight: 54.4 kg
Height: 432 mm
Packaging data
Temperature sensor: Yes
Package height: 330 mm
Warranty card: Yes
Package width: 610 mm
Packaging content
Quick installation guide: Yes
Cables included: USB cable
Management card included: Yes
Certification: REACH, CE, CE Mark, EAC, EN/IEC 62040-1, EN/IEC 62040-2, IRAM, RCM, VDE
Certificates
Compliance certificates: RoHS
Ports & interfaces
AC outlet types: C13 coupler, C19 coupler
Power plug: Hardwire
Number of output IEC jumpers: 2
USB port: Yes
SmartSlot: Yes
Serial interface type: RJ-45
Serial interface: Yes
AC outlets quantity: 12 AC outlet(s)
SmartConnect port: No
Battery
Battery technology: Sealed Lead Acid (VRLA)
Battery life (max): 5 year(s)
Hot-swap battery: Yes
Automatic battery test: Yes
Battery capacity: 845 VAh
Cold start: Yes
Typical backup time at full load: 4 min
Battery recharge time: 1.5 h
Typical backup time at half load: 11.8 min
Logistics data
Harmonized System (HS) code: 85078000
Total carbon footprint (kg of CO2e): 8386.06
Sustainability
Sustainability certificates: ENERGY STAR
