Features
UPS topology: Line-Interactive
Input frequency: 50/60 Hz
Audible alarm modes: Low battery alarm, Overload alarm
Output power capacity: 1.5 kVA
Waveform: Sine
Output frequency regulation: 50/60 Hz
Automatic Voltage Regulation (AVR): Yes
Auto-restart: Yes
Audible alarm(s): Yes
Noise level: 40 dB
Surge energy rating: 645 J
Output power: 1200 W
Efficiency: 98.5%
Emergency Power Off (EPO): Yes
Input operation voltage (max): 302 V
Input operation voltage (min): 151 V
Design
Form factor: Rackmount/Tower
Rack capacity: 2U
Cable length: 1.83 m
LED indicators: Yes
Product colour: Black
Operational conditions
Operating relative humidity (H-H): 0 - 95%
Storage relative humidity (H-H): 0 - 95%
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -15 - 45 °C
Operating altitude: 0 - 3000 m
Non-operating altitude: 0 - 15000 m
Weight & dimensions
Weight: 24.8 kg
Depth: 490 mm
Width: 432 mm
Height: 89 mm
Packaging data
Package width: 589 mm
Package height: 246 mm
Package weight: 30 kg
Software CD: Yes
Package depth: 620 mm
Packaging content
Management card included: No
Rack mount kit: Yes
Cables included: RS-232, USB cable
Quick installation guide: Yes
Certification: CE, EN/IEC 62040-1, EN/IEC 62040-2, RCM, VDE, REACH, PEP, EOLI
Certificates
Compliance certificates: RoHS
Ports & interfaces
AC outlet types: C13 coupler
USB port: Yes
AC outlets quantity: 8 AC outlet(s)
Power plug: C14 coupler
Number of output IEC jumpers: 2
SmartConnect port: No
SmartSlot: Yes
Battery
Automatic battery test: Yes
Typical backup time at half load: 17.2 min
Battery technology: Sealed Lead Acid (VRLA)
Battery capacity: 311 VAh
Cold start: Yes
Battery life (max): 5 year(s)
Typical backup time at full load: 5.8 min
Hot-swap battery: Yes
Battery recharge time: 3 h
Packaging content: Removable support feet
Other features
Nominal input voltage: 230 V
Nominal output voltage: 230 V
Logistics data
Harmonized System (HS) code: 85078000
Products per pallet: 8 pc(s)
Total carbon footprint (kg of CO2e): 1419.64
