Features
Audible alarm(s): Yes
Efficiency: 98.1%
Output power capacity: 2.2 kVA
Output power: 1980 W
Emergency Power Off (EPO): Yes
Surge protection: Yes
Input frequency: 50/60 Hz
Noise level: 55 dB
Output operation voltage (min): 208 V
Output operation voltage (max): 240 V
Input operation voltage (min): 140 V
Input operation voltage (max): 280 V
Output frequency regulation: 50/60 Hz
Hold time (min): 2 ms
UPS topology: Line-Interactive
Hold time (max): 10 ms
Waveform: Sine
Surge energy rating: 645 J
Auto-restart: Yes
Automatic Voltage Regulation (AVR): Yes
Design
Product colour: Black
Cable length: 2 m
Display type: LCD
Rack capacity: 4U
Form factor: Rackmount/Tower
LED indicators: Status, Battery replacement
Operational conditions
Storage temperature (T-T): -15 - 45 °C
Storage relative humidity (H-H): 0 - 95%
Operating relative humidity (H-H): 0 - 95%
Non-operating altitude: 0 - 15000 m
Operating temperature (T-T): 0 - 40 °C
Operating altitude: 0 - 3000 m
Weight & dimensions
Weight: 38.6 kg
Width: 178 mm
Depth: 483 mm
Height: 432 mm
Packaging data
Package depth: 633 mm
Package width: 586 mm
Package weight: 47.7 kg
Package height: 330 mm
Temperature sensor: Yes
Software CD: Yes
Packaging content
Quick installation guide: Yes
Rack mount kit: Yes
Manual: Yes
Cables included: RS-232, USB cable
Certification: CE, CSA, EAC, EN 50091-1, EN 50091-2, EN/IEC 62040-1, EN/IEC 62040-2, FCC Part 15 CL A, IEC 60950, IRAM, RCM, UL 1778, VDE, WEEE, REACH
Certificates
Compliance certificates: RoHS
Ports & interfaces
AC outlet types: C13 coupler, C19 coupler
AC outlets quantity: 10 AC outlet(s)
USB port: Yes
Power plug: C20 coupler
SmartSlot: Yes
Number of output IEC jumpers: 2
Battery
Cold start: Yes
Battery technology: Sealed Lead Acid (VRLA)
Typical backup time at half load: 25.3 min
Automatic battery test: Yes
Typical backup time at full load: 9.8 min
Battery recharge time: 3 h
Hot-swap battery: Yes
Battery capacity: 702 VAh
Battery life (max): 5 year(s)
Logistics data
Harmonized System (HS) code: 85078000
Products per pallet: 6 pc(s)
Total carbon footprint (kg of CO2e): 3397.7
