Features
Output power: 1980 W
Input frequency: 50/60 Hz
Input operation voltage (max): 230 V
Emergency Power Off (EPO): Yes
Web-based management: Yes
Output power capacity: 2.2 kVA
Output operation voltage (min): 208 V
Input operation voltage (min): 208 V
Noise level: 55 dB
Audible alarm modes: Battery replacement
Response time: 10 ms
Output operation voltage (max): 240 V
Audible alarm(s): Yes
Surge protection: Yes
Waveform: Sine
Auto-restart: Yes
UPS topology: Line-Interactive
Output voltage regulation: 5%
Output frequency: 50/60 Hz
Surge energy rating: 645 J
Output frequency regulation: +/- 3 Hz
Design
Display type: LCD
Rack capacity: 2U
Form factor: Rackmount/Tower
LED indicators: Yes
Product colour: Black
Operational conditions
Storage relative humidity (H-H): 0 - 95%
Operating altitude: 0 - 3000 m
Storage temperature (T-T): -15 - 45 °C
Operating relative humidity (H-H): 0 - 95%
Operating temperature (T-T): 0 - 40 °C
Non-operating altitude: 0 - 15000 m
Weight & dimensions
Weight: 37.4 kg
Width: 432 mm
Height: 85 mm
Depth: 667 mm
Packaging data
Package weight: 45.3 kg
Package height: 243 mm
Package depth: 869 mm
Package width: 596 mm
Resource CD: Yes
Packaging content
Cables included: Input power cable, USB cable
Quick installation guide: Yes
Management card included: Yes
Rack mount kit: Yes
Certification: CE, EAC, EN/IEC 62040-1, EN/IEC 62040-2, GS Mark, IRAM, RCM, VDE, WEEE
Certificates
Compliance certificates: RoHS
Ports & interfaces
AC outlets quantity: 9 AC outlet(s)
AC outlet types: C19 coupler, C13 coupler
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 1
Power plug: C20 coupler
SmartConnect port: No
SmartSlot: Yes
Battery
Battery capacity: 702 Ah
Cold start: Yes
Battery recharge time: 3 h
Battery technology: Sealed Lead Acid (VRLA)
Automatic battery test: Yes
Hot-swap battery: Yes
Other features
Output voltage: 230 V
Logistics data
Total carbon footprint (kg of CO2e): 3167.15
Products per pallet: 8 pc(s)
Harmonized System (HS) code: 85078000
