Features
Output frequency regulation: 50/60 Hz
Auto-restart: Yes
Waveform: Sine
Audible alarm(s): Yes
Efficiency: 98.5%
Surge energy rating: 645 J
UPS topology: Line-Interactive
Output power: 2700 W
Output power capacity: 3 kVA
Surge protection: Yes
Input frequency: 50/60 Hz
Hold time (max): 10 ms
Output operation voltage (min): 208 V
Emergency Power Off (EPO): Yes
Automatic Voltage Regulation (AVR): Yes
Input operation voltage (max): 280 V
Input operation voltage (min): 140 V
Noise level: 55 dB
Output operation voltage (max): 240 V
Hold time (min): 2 ms
Crest factor: 3:1
Design
Display type: LCD
Cable length: 1.83 m
LED indicators: Status
Product colour: Black
Form factor: Rackmount/Tower
Rack capacity: 4U
Operational conditions
Storage relative humidity (H-H): 0 - 95%
Operating altitude: 0 - 3000 m
Operating relative humidity (H-H): 0 - 95%
Storage temperature (T-T): -15 - 45 °C
Non-operating altitude: 0 - 15000 m
Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
Height: 432 mm
Width: 178 mm
Depth: 483 mm
Weight: 38.6 kg
Packaging data
Package width: 586 mm
Package weight: 47.7 kg
Package height: 330 mm
Package depth: 633 mm
Software CD: Yes
Packaging content
Management card included: No
Cables included: RS-232, USB cable
Rack mount kit: Yes
Quick installation guide: Yes
Manual: Yes
Certification: C-tick, CE, CSA, EN 50091-1, EN 50091-2, EN 60950, FCC Part 15 Class A, GOST, IRAM, UL 1778, VDE,
REACH
Certificates
Compliance certificates: RoHS
Ports & interfaces
SmartSlot: Yes
AC outlet types: C13 coupler, C19 coupler
Number of output IEC jumpers: 2
AC outlets quantity: 10 AC outlet(s)
Power plug: C20 coupler
SmartConnect port: No
Battery
Battery capacity: 738 VAh
Battery life (max): 5 year(s)
Typical backup time at full load: 6.25 min
Hot-swap battery: Yes
Automatic battery test: Yes
Typical backup time at half load: 18 min
Battery recharge time: 3 h
Battery technology: Sealed Lead Acid (VRLA)
Other features
Nominal output voltage: 230 V
Logistics data
Harmonized System (HS) code: 85078000
Products per pallet: 6 pc(s)
Total carbon footprint (kg of CO2e): 2447.6
