Features
Output power capacity: 3 kVA
Output power: 2700 W
Noise level: 55 dB
Audible alarm(s): Yes
Input frequency: 50/60 Hz
Hold time (max): 10 ms
UPS topology: Line-Interactive
Surge energy rating: 645 J
Hold time (min): 2 ms
Input operation voltage (max): 280 V
Output operation voltage (max): 240 V
Waveform: Sine
Efficiency: 98.5%
Automatic Voltage Regulation (AVR): Yes
Input operation voltage (min): 140 V
Output operation voltage (min): 208 V
Surge protection: Yes
Emergency Power Off (EPO): Yes
Auto-restart: Yes
Design
Product colour: Black
LED indicators: Status, Battery replacement
Cable length: 2.44 m
Rack capacity: 4U
Form factor: Rackmount/Tower
Display type: LCD
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating altitude: 0 - 3000 m
Storage temperature (T-T): -15 - 45 °C
Operating relative humidity (H-H): 0 - 95%
Storage relative humidity (H-H): 0 - 95%
Non-operating altitude: 0 - 15000 m
Weight & dimensions
Weight: 38.6 kg
Depth: 483 mm
Height: 432 mm
Width: 178 mm
Packaging data
Package depth: 633 mm
Package weight: 47.7 kg
Package width: 586 mm
Package height: 330 mm
Software CD: Yes
Temperature sensor: Yes
Packaging content
Manual: Yes
Cables included: RS-232
Management card included: Yes
Rack mount kit: Yes
Certification: C-tick, CE, CSA, EN 50091-1, EN 50091-2, EN 55022 Class A, EN 60950, FCC Part 15 Class A, GOST, IRAM, UL 1778, VDE, REACH
Certificates
Compliance certificates: RoHS
Ports & interfaces
Power plug: C20 coupler
AC outlets quantity: 10 AC outlet(s)
SmartConnect port: No
SmartSlot: Yes
AC outlet types: C19 coupler, C13 coupler
Number of output IEC jumpers: 2
Battery
Battery technology: Sealed Lead Acid (VRLA)
Automatic battery test: Yes
Typical backup time at full load: 6.25 min
Typical backup time at half load: 18 min
Battery recharge time: 3 h
Battery capacity: 738 VAh
Battery life (max): 5 year(s)
Hot-swap battery: Yes
Packaging content: Web/SNMP Management Card
Other features
Nominal output voltage: 230 V
Logistics data
Total carbon footprint (kg of CO2e): 2790.64
Products per pallet: 6 pc(s)
Harmonized System (HS) code: 85078000
Safety warning
Warnings: Do not disassemble the unit housing, there may be a risk of electric shock., Use the appliance in well-ventilated areas to avoid overheating., Keep away from sources of fire and water.
