Features Output power capacity: 3000 kVA Noise level: 55 dB Efficiency: 98.9% Input operation voltage (min): 151 V Hold time (min): 4 ms UPS topology: Line-Interactive Waveform: Sine Input frequency: 50/60 Hz Output power: 2700 W Audible alarm(s): Yes Hold time (max): 8 ms Input operation voltage (max): 302 V Surge energy rating: 320 J Output operation voltage (min): 220 V Automatic Voltage Regulation (AVR): Yes Auto-restart: Yes Output operation voltage (max): 240 V
Design LED indicators: Status Cable length: 2 m Product colour: Black Rack capacity: 2U RoHS compliance: Y
Operational conditions Operating altitude: 0 - 3000 m Operating temperature (T-T): 0 - 40 °C Storage relative humidity (H-H): 0 - 95% Storage temperature (T-T): -15 - 45 °C Operating relative humidity (H-H): 0 - 95% Non-operating altitude: 0 - 15000 m
Weight & dimensions Width: 480 mm Height: 86 mm Depth: 683 mm Weight: 44.3 kg
Packaging data Cables included: USB cable, RS-232 Quick installation guide: Yes Rack mount kit: Yes
Ports & interfaces AC outlets quantity: 9 AC outlet(s) Number of output IEC jumpers: 3 AC outlet types: C19 coupler, C13 coupler Serial interface: Yes USB port: Yes SmartSlot: Yes Serial interface type: RJ-45
Battery Cold start: Yes Battery technology: Sealed Lead Acid (VRLA) Typical backup time at full load: 3.2 min Battery life (max): 5 year(s) Typical backup time at half load: 11.5 min Battery capacity: 547 VAh Automatic battery test: Yes Hot-swap battery: Yes Battery recharge time: 3 h
Other features Nominal input voltage: 230 V Nominal output voltage: 230 V
