Design
Product colour: Aluminium, Black
Rack capacity: 4U
Fins material: Aluminium
Fan connector: 4-pin
Number of heat pipes: 8
Number of fins: 57
Number of fans: 2 fan(s)
Power
Fan voltage: 12 V
Thermal Design Power (TDP): 350 W
Fan current: 0.12 A
Starting voltage: 8 V
Weight & dimensions
Cable length: 0.2 m
Package weight: 1.55 kg
Package height: 141 mm
Heat pipes diameter: 6 mm
Height: 145 mm
Depth: 124 mm
Weight: 1.27 kg
Width: 156 mm
Package depth: 211 mm
Package width: 160 mm
Performance
Fan speed (max): 2300 RPM
Supported processor sockets: SP6, Socket TR4, Socket sTRX4, LGA 4189, Socket sWRX8, LGA 4677 (Socket E), LGA 4710 (Socket E2), Socket TR5
Fan noise level (max): 40 dB
Fan static pressure: 3.3 mmH2O
Operating temperature (T-T): 0 - 40 °C
Bearing type: Dual ball bearing
Maximum airflow: 71.9 cfm
Suitable location: Processor
Fan diameter: 12 cm
Type: Air cooler
Airflow: 122.16 m³/h
Fan speed (min): 400 RPM
Packaging content
Package type: Box
