Design Number of fans: 2 fan(s) Radiator material: Aluminum Illumination colour: Multi Base plate material: Copper Fan connector: 4-pin LED connector type: 3-pin Illumination LED: Yes Product colour: White
Power Fan voltage: 12 V Pump voltage: 12 V LED voltage: 5 V Pump current: 350 mA Fan current: 0.17 A
Weight & dimensions Pump depth: 10.8 cm Pump width: 9.1 cm Package height: 155 mm Package weight: 2.3 kg Package width: 170 mm Radiator width: 13.8 cm Tube diameter: 1.24 cm Tube inner diameter: 6 mm Radiator height: 3.8 cm Pump height: 6.85 cm Radiator depth: 31.7 cm Tube length: 45 cm Package depth: 355 mm Fan dimensions (W x D x H): 140 x 140 x 27 mm Weight: 1.76 kg Cable length: 0.04 m
Performance Airflow: 117.06 m³/h VRM fan speed (max): 2500 RPM Supported processor sockets: LGA 1700, Socket AM4, Socket AM5, Intel LGA1851 Quantity per pack: 1 pc(s) Pump connector: 4-pin Fan speed (min): 200 RPM Type: All-in-one liquid cooler Pulse-width modulation (PWM) support: Yes Bearing type: Fluid Dynamic Bearing (FDB) Suitable location: Processor Operating temperature (T-T): 0 - 40 °C Fan static pressure: 2 mmH2O Maximum airflow: 69.9 cfm Pump motor speed (min): 800 RPM VRM fan speed (min): 400 RPM Pump motor speed (max): 2800 RPM Fan diameter: 14 cm Fan speed (max): 1900 RPM
Packaging content Package type: Hanging box
Other features Country of origin: Hong Kong
Safety warning Warnings: Do not touch the fan during operation., Take appropriate precautions during installation to avoid damage to computer components., Ensure that the unit is switched off before starting to assemble or dismantle the cooling unit.
