Design Base plate material: Copper Radiator material: Aluminum LED connector type: 3-pin Product colour: White Fan connector: 4-pin Number of fans: 2 fan(s) Illumination colour: Multi Illumination LED: Yes
Power Fan voltage: 12 V Fan current: 0.33 A LED voltage: 5 V Pump voltage: 12 V Pump current: 350 mA
Weight & dimensions Tube diameter: 1.24 cm Radiator height: 3.8 cm Tube inner diameter: 6 mm Radiator depth: 27.7 cm Pump height: 6.85 cm Pump depth: 10.8 cm Radiator width: 12 cm Cable length: 0.04 m Pump width: 9.1 cm Tube length: 45 cm Fan dimensions (W x D x H): 120 x 120 x 25 mm Package width: 171 mm Weight: 1.67 kg Package weight: 2.06 kg Package height: 142 mm Package depth: 294 mm
Performance VRM fan speed (max): 2500 RPM Pump connector: 4-pin Fan speed (min): 600 RPM Suitable location: Processor VRM fan speed (min): 400 RPM Fan speed (max): 3000 RPM Pump motor speed (max): 2800 RPM Fan static pressure: 6.9 mmH2O Pump motor speed (min): 800 RPM Airflow: 131 m³/h Pulse-width modulation (PWM) support: Yes Fan diameter: 12 cm Type: All-in-one liquid cooler Supported processor sockets: LGA 1851, Socket AM5, LGA 1700, Socket AM4 Maximum airflow: 77 cfm Bearing type: Fluid Dynamic Bearing (FDB) Operating temperature (T-T): 0 - 40 °C Quantity per pack: 1 pc(s)
