Design Number of fans: 2 fan(s) LED connector type: 3-pin Radiator material: Aluminum Fan connector: 4-pin Illumination colour: Multi Product colour: Black Illumination LED: Yes Base plate material: Copper
Power Pump current: 350 mA Pump voltage: 12 V Fan current: 0.35 A LED voltage: 5 V Fan voltage: 12 V
Weight & dimensions Package weight: 2.31 kg Weight: 1.91 kg Package height: 155 mm Fan dimensions (W x D x H): 140 x 140 x 27 mm Package width: 170 mm Package depth: 335 mm Pump width: 9.1 cm Tube diameter: 1.24 cm Radiator width: 13.8 cm Radiator height: 3.8 cm Pump height: 6.85 cm Pump depth: 10.8 cm Radiator depth: 31.7 cm Tube length: 45 cm Tube inner diameter: 6 mm
Performance Airflow: 186 m³/h Maximum airflow: 110 cfm Supported processor sockets: LGA 1700, Socket AM5, LGA 1851, Socket AM4 Pulse-width modulation (PWM) support: Yes Fan diameter: 14 cm Type: All-in-one liquid cooler Fan speed (min): 400 RPM Bearing type: Fluid Dynamic Bearing (FDB) Operating temperature (T-T): 0 - 40 °C Fan static pressure: 5.2 mmH2O Quantity per pack: 1 pc(s) Pump motor speed (min): 800 RPM Suitable location: Processor Pump connector: 4-pin Fan speed (max): 2500 RPM Pump motor speed (max): 2800 RPM VRM fan speed (max): 2500 RPM VRM fan speed (min): 400 RPM
