Design Product colour: Black Number of fans: 2 fan(s) Radiator material: Aluminum Fan connector: 4-pin Base plate material: Copper
Power Pump current: 350 mA Pump voltage: 12 V Fan current: 0.35 A Fan voltage: 12 V
Weight & dimensions Package height: 155 mm Package weight: 2.32 kg Package depth: 335 mm Fan dimensions (W x D x H): 140 x 140 x 27 mm Package width: 170 mm Weight: 1.91 kg Tube length: 45 cm Radiator height: 3.8 cm Pump depth: 10.8 cm Tube diameter: 1.24 cm Tube inner diameter: 6 mm Pump height: 6.85 cm Radiator depth: 31.7 cm Radiator width: 13.8 cm Pump width: 9.1 cm
Performance Supported processor sockets: Socket AM4, LGA 1851, Socket AM5, LGA 1700 Fan static pressure: 5.2 mmH2O Operating temperature (T-T): 0 - 40 °C Bearing type: Fluid Dynamic Bearing (FDB) Maximum airflow: 110 cfm Fan speed (min): 400 RPM Pump motor speed (max): 2800 RPM Fan speed (max): 2500 RPM Pulse-width modulation (PWM) support: Yes Fan diameter: 14 cm Airflow: 186 m³/h Pump motor speed (min): 800 RPM Quantity per pack: 1 pc(s) Type: All-in-one liquid cooler VRM fan speed (max): 2500 RPM Pump connector: 4-pin Suitable location: Processor VRM fan speed (min): 400 RPM
