Design Product colour: Black Radiator material: Aluminum LED connector type: 3-pin + 3-pin Number of fans: 3 fan(s) Illumination colour: Multi Fan connector: 4-pin Base plate material: Copper Illumination LED: Yes
Power Fan voltage: 12 V Pump voltage: 12 V Fan current: 0.35 A Pump current: 0.35 mA LED voltage: 5 V
Weight & dimensions Package width: 328 mm Package height: 158 mm Depth: 68 mm Package weight: 2.98 kg Weight: 2.36 kg Height: 138 mm Width: 458 mm Package depth: 447 mm Tube inner diameter: 6 mm Tube length: 50 cm Radiator depth: 45.8 cm Tube diameter: 1.24 cm Radiator width: 13.8 cm Radiator height: 3.8 cm
Performance Operating temperature (T-T): 0 - 40 °C Bearing type: Fluid Dynamic Bearing (FDB) Type: All-in-one liquid cooler Supported processor sockets: Socket AM5, Socket AM4, LGA 1851, LGA 1700 Maximum air pressure: 5.2 mmH2O Rotational speed (min): 400 RPM Airflow: 186 m³/h Pump motor speed (max): 2800 RPM Pump motor speed (min): 800 RPM Fan diameter: 14 cm Rotational speed (max): 2500 RPM Maximum airflow: 110 cfm Suitable location: Processor Pulse-width modulation (PWM) support: Yes VRM fan speed (max): 2500 RPM VRM fan speed (min): 400 RPM
