Design Number of fans: 3 fan(s) Radiator material: Aluminum Fan connector: 4-pin Product colour: Black Base plate material: Copper
Power Pump current: 350 mA Fan voltage: 12 V Fan current: 0.35 A Pump voltage: 12 V
Weight & dimensions Pump height: 6.85 cm Package width: 328 mm Fan dimensions (W x D x H): 120 x 120 x 25 mm Package weight: 2.99 kg Weight: 2.37 kg Package height: 158 mm Package depth: 447 mm Tube length: 45 cm Tube inner diameter: 6 mm Pump depth: 10.8 cm VRM fan diameter: 9.1 cm Radiator depth: 45.8 cm Tube diameter: 1.24 cm Radiator width: 13.8 cm Radiator height: 3.8 cm Pump width: 9.1 cm
Performance Pulse-width modulation (PWM) support: Yes Operating temperature (T-T): 0 - 40 °C Pump motor speed (min): 800 RPM Fan speed (min): 400 RPM Fan static pressure: 5.2 mmH2O Fan speed (max): 2500 RPM Airflow: 186 m³/h Bearing type: Fluid Dynamic Bearing (FDB) Fan diameter: 12 cm Pump motor speed (max): 2800 RPM Maximum airflow: 110 cfm Supported processor sockets: Socket AM4, Socket AM5, LGA 1851, LGA 1700 Type: Liquid cooling kit Quantity per pack: 1 pc(s) VRM fan speed (min): 400 RPM VRM fan speed (max): 2500 RPM Suitable location: Processor
