Features
MIMO: Yes
Spread spectrum method: OFDMA, DSSS, OFDM
Modulation: 256-QAM, CCK, 16-QAM, BPSK, 64-QAM, QPSK, 1024-QAM
Frequency band: 20/40 (2.4 GHz), 20/40/80 (5 GHz), maximum peak data rate 1.49 Gbps
Maximum data transfer rate: 1774 Mbit/s
2.4 GHz: Yes
Ethernet LAN data rates: 1000 Mbit/s
Networking standards: IEEE 802.11mc, IEEE 802.11ax
5 GHz: Yes
MIMO type: Multi User MIMO
Auto MDI/MDI-X: Yes
Maximum data transfer rate (2.4 GHz): 574 Mbit/s
Maximum data transfer rate (5 GHz): 1200 Mbit/s
Design
Product colour: White
Cable lock slot: Yes
Placement: Ceiling, Wall
Recommended usage: Indoor
Cable lock slot type: Kensington
Power
Power consumption (max): 16.5 W
Power over Ethernet (PoE): Yes
Security
Security algorithms: WPA3, WPA, WPA2
Operational conditions
Operating temperature (T-T): 0 - 50 °C
Storage temperature (T-T): -40 - 70 °C
Storage relative humidity (H-H): 5 - 93%
Operating relative humidity (H-H): 5 - 93%
Weight & dimensions
Height: 37 mm
Weight: 500 g
Depth: 161 mm
Width: 160 mm
Certification: UL2043 plenum rating Wi‑Fi Alliance: Wi-Fi CERTIFIED a, b, g, n, ac Wi-Fi CERTIFIED 6 (ax) WPA, WPA2 and WPA3-Enterprise with CNSA option, Personal (SAE), Enhanced Open (OWE) WMM, WMM-PS, W-Fi Agile Multiband Wi-Fi CERTIFIED Location Bluetooth SIG Ethernet Alliance (PoE, PD device, Class 4)
Certificates
Compliance certificates: Low Voltage Directive (LVD), CE, Electromagnetic Compatibility (EMC), ISED, Federal Communications Commission (FCC)
Ports & interfaces
USB connector type: USB Type-A
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 1
Antenna
Antenna type: Internal
Antennas quantity: 2
Antenna direction type: Omni-directional
Antenna features: Integrated antenna
I/O ports: E0: Ethernet wired network port (RJ-45) USB 2.0 host interface (Type A connector) Serial console interface (proprietary, micro-B USB physical jack) Kensington security slot.
Other features
Weight (imperial): 0.499 kg (1.1 lbs)
Logistics data
Harmonized System (HS) code: 85176990
Safety warning
Warnings: Do not expose to prolonged moisture., Avoid direct contact with water., Electronic products should be recycled at specialist electronic waste collection facilities.
