Design
Form factor: 1U
Rack mounting: Yes
Power
Power supply included: Yes
AC input frequency: 50 - 60 Hz
AC input voltage: 100 - 240 V
Power consumption (max): 462.5 W
Power source: AC
Security
DHCP features: DHCP client
SSH/SSL support: Yes
IGMP snooping: Yes
Management features
Switch layer: L2
Cloud-managed: Yes
Switch type: Managed
Web-based management: Yes
Quality of Service (QoS) support: Yes
Weight & dimensions
Weight: 4.94 kg
Height: 43.9 mm
Width: 351 mm
Depth: 443 mm
Network
Full duplex: Yes
Auto-sensing: Yes
Flow control support: Yes
Spanning tree protocol: Yes
Link aggregation: Yes
Port mirroring: Yes
10G support: No
Networking standards: IEEE 802.3ad, IEEE 802.3at, IEEE 802.1D, IEEE 802.3z, IEEE 802.1Q, IEEE 802.3x, IEEE 802.1ab, IEEE 802.3u, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3az, IEEE 802.1w, IEEE 802.3ac
Auto MDI/MDI-X: Yes
VLAN support: Yes
Performance
Memory type: SDRAM
Processor frequency: 800 MHz
Internal memory: 512 MB
Processor model: ARM Cortex-A9
Flash memory: 256 MB
Built-in processor: Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity: 48
SFP module slots quantity: 4
Data transmission
Latency (10-100 Mbps): 5.2 µs
Switching capacity: 104 Gbit/s
MAC address table: 16000 entries
Jumbo frames support: Yes
Packet buffer memory: 1.5 MB
Throughput: 77.37 Mpps
Latency (1 Gbps): 2.8 µs
Power over Ethernet (PoE)
Power over Ethernet (PoE): Yes
Total Power over Ethernet (PoE) budget: 370 W
Safety warning
Warnings: Do not expose to prolonged moisture., Electronic products should be recycled at specialist electronic waste collection facilities., Avoid direct contact with water.
