Processor
Compatible processor series: AMD Ryzen 3000 Series
Processor manufacturer: AMD
Processor socket: Socket AM4
Graphics
Graphics card: Radeon Vega
Graphics card family: AMD
Features
Motherboard chipset: AMD A520
Audio output channels: 7.1 channels
Motherboard chipset family: AMD
Motherboard form factor: micro ATX
Memory
Memory channels: Dual-channel
Unbuffered memory: Yes
Memory slots type: DIMM
Number of memory slots: 2
Supported memory types: DDR4-SDRAM
Maximum internal memory: 64 GB
Supported memory clock speeds: 3733, 3866, 3200 MHz, 2666, 4266, 2133, 4133, 4000, 3466, 2933, 3600, 4533, 4333, 2400, 4400 MHz, 4200, 4500, 3800, 4466
ECC сompatibility: Non-ECC
Weight & dimensions
Width: 230 mm
Depth: 201 mm
Network
Ethernet interface type: Gigabit Ethernet
Wi-Fi: No
Ethernet LAN: Yes
Wake-on-LAN ready: Yes
LAN controller: Realtek RTL8111H
Internal I/O
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
ATX Power connector (24-pin): Yes
Number of COM connectors: 1
Front panel audio connector: Yes
CPU fan connector: Yes
USB 2.0 connectors: 2
Number of chassis fan connectors: 2
BIOS
BIOS type: UEFI AMI
Packaging content
Drivers included: Yes
Cables included: SATA
Storage controllers
Number of HDDs supported: 5
Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 2
PS/2 ports quantity: 1
VGA (D-Sub) ports quantity: 1
Microphone in: Yes
Expansion slots
PCI Express x16 (Gen 3.x) slots: 1
PCI Express x1 (Gen 3.x) slots: 1
Logistics data
Harmonized System (HS) code: 84733020
Safety warning
Warnings: Dispose of according to local electro-waste regulations., Avoid direct contact with sensitive electronic components., Store away from water and sources of moisture.
