Processor
Compatible processor series: 3rd Generation AMD Ryzen 5, 2nd Generation AMD Ryzen™ 7, 3rd Generation AMD Ryzen™ 9, 3rd Generation AMD Ryzen™ 3
Processor manufacturer: AMD
Processor socket: Socket AM4
Graphics
Graphics card: Radeon Vega
Graphics card family: AMD
Features
Motherboard chipset family: AMD
Audio output channels: 7.1 channels
Motherboard form factor: micro ATX
Memory
Memory slots type: DIMM
Supported memory clock speeds: 3866, 3800, 4466, 3200, 4266, 2667, 3733, 4400, 3466, 2400, 4133, 4000, 2933, 4333, 2133 MHz, 4200
Maximum internal memory: 64 GB
Memory channels: Dual-channel
Number of memory slots: 2
Supported memory types: DDR4-SDRAM
Weight & dimensions
Depth: 201 mm
Width: 230 mm
Network
LAN controller: Realtek RTL8111H
Wake-on-LAN ready: Yes
Ethernet LAN: Yes
Wi-Fi: Yes
Bluetooth: Yes
Bluetooth version: 4.2
Wi-Fi standards: Wi-Fi 5 (802.11ac)
Ethernet interface type: Gigabit Ethernet
Internal I/O
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Number of COM connectors: 1
Front panel audio connector: Yes
CPU fan connector: Yes
Number of chassis fan connectors: 2
ATX Power connector (24-pin): Yes
USB 2.0 connectors: 2
BIOS
BIOS type: UEFI AMI
Packaging content
Cables included: SATA
Storage controllers
Number of HDDs supported: 5
Supported storage drive interfaces: M.2, Serial ATA III
Rear panel I/O ports
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
Ethernet LAN (RJ-45) ports: 1
PS/2 ports quantity: 1
USB 2.0 ports quantity: 2
VGA (D-Sub) ports quantity: 1
HDMI ports quantity: 1
