Technical details
Compliance certificates: Federal Communications Commission (FCC), CE
Processor
Processor manufacturer: AMD
Compatible processor series: AMD Ryzen 9000 Series, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series
Processor socket: Socket AM5
Graphics
Maximum resolution: 3840 x 2160 pixels
HDCP: Yes
Graphics card: AMD RDNA 2
On-board graphics card: Yes
Graphics card family: AMD
HDCP version: 2.3
High Dynamic Range (HDR) supported: Yes
Features
Audio chip: Realtek ALC897
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Audio output channels: 7.1 channels
Motherboard chipset family: AMD
Product colour: Black
Motherboard chipset: AMD A620A
Motherboard form factor: micro ATX
Memory
Unbuffered memory: Yes
Memory channels: Dual-channel
Supported memory clock speeds: 8000
Maximum internal memory: 256 GB
Number of memory slots: 4
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
ECC сompatibility: ECC & Non-ECC
Weight & dimensions
Width: 244 mm
Depth: 244 mm
Network
LAN controller: Dragon RTL8125BG
Antenna type: 2 x 2
Bluetooth: Yes
Top Wi-Fi standard: Wi-Fi 6E (802.11axe)
Wi-Fi standards: 802.11g, 802.11ac, 802.11n, 802.11 axe, 802.11 ax, 802.11b, 802.11a
Ethernet interface type: 2.5 Gigabit Ethernet, Gigabit Ethernet, Fast Ethernet
Bluetooth version: 5.2
Ethernet LAN: Yes
Wi-Fi: Yes
Internal I/O
ATX Power connector (24-pin): Yes
Number of SATA III connectors: 2
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
USB 2.0 connectors: 2
CPU fan connector: Yes
Number of chassis fan connectors: 3
TPM connector: Yes
Front panel audio connector: Yes
RGB LED pin header: Yes
12V power connector: Yes
Number of water pump connectors: 1
Number of CPU fan connectors: 2
Number of RGB LED pin headers: 1
BIOS
BIOS type: UEFI AMI
BIOS flashback button: Yes
Packaging content
Cables included: SATA
Storage controllers
RAID support: Yes
Supported storage drive interfaces: M.2, NVMe, SATA III
RAID levels: 1, 0, 10
Supported storage drive types: HDD & SSD
Number of HDDs supported: 2
Rear panel I/O ports
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 4
HDMI version: 2.1
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
Antennas quantity: 2
Expansion slots
Number of M.2 (M) slots: 3
PCI Express x16 (Gen 4.x) slots: 1
Processor special features
Intel Extreme Memory Profile (XMP): Yes
AMD Extended Profiles for Overclocking (EXPO): Yes
