Processor
Processor manufacturer: AMD
Compatible processor series: AMD Ryzen PRO 8000 Series, AMD Ryzen Threadripper PRO 5000 WX-Series, AMD Ryzen 7000 Series, AMD Ryzen Threadripper PRO 7000 WX-Series, AMD Ryzen Threadripper 7000 Series, AMD Ryzen 9000 Series, AMD Ryzen PRO 7000 Series, AMD Ryzen 8000 Series
Processor socket: Socket AM5
Features
Audio chip: Realtek ALC897
Motherboard chipset: AMD A620A
Motherboard chipset family: AMD
Motherboard form factor: micro ATX
Component for: PC
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Audio output channels: 7.1 channels
Memory
Maximum internal memory: 256 GB
Memory channels: Dual-channel
Supported memory types: DDR5-SDRAM
Number of memory slots: 4
Memory slots type: DIMM
ECC сompatibility: ECC & Non-ECC
Weight & dimensions
Width: 244 mm
Depth: 244 mm
Network
LAN controller: Dragon RTL8125AG
Ethernet interface type: 2.5 Gigabit Ethernet
Wi-Fi: No
Ethernet LAN: Yes
Internal I/O
TPM connector: Yes
USB 2.0 connectors: 2
Number of SATA III connectors: 2
CPU fan connector: Yes
EPS power connector (8-pin): Yes
Front panel audio connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
ATX Power connector (24-pin): Yes
RGB LED pin header: Yes
Number of CPU fan connectors: 1
Number of EPS power connectors (8-pin): 1
BIOS
BIOS type: UEFI AMI
BIOS memory size: 256 Mbit
Packaging content
Cables included: SATA
Screws included: Yes
Storage controllers
Supported storage drive types: HDD & SSD
RAID support: Yes
RAID levels: 10, 0, 1
Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports
USB 2.0 ports quantity: 4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
DisplayPort version: 1.4
DisplayPorts quantity: 1
HDMI ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
Line-in: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
Microphone in: Yes
Expansion slots
PCI Express x16 (Gen 3.x) slots: 1
Number of M.2 (M) slots: 1
PCI Express x16 (Gen 4.x) slots: 1
