Processor
Compatible processor series: AMD Ryzen™ 8000 Series, AMD Ryzen 9000 Series, AMD Ryzen 7000 Series
Processor socket: Socket AM5
Processor manufacturer: AMD
Graphics
Graphics card: AMD RDNA 2
On-board graphics card: Yes
Graphics card family: AMD
Certification: FCC, CE- ErP/EuP ready (ErP/EuP ready power supply is required)
Features
Motherboard chipset family: AMD
Audio output channels: 7.1 channels
Motherboard form factor: micro ATX
Motherboard chipset: AMD A620
Windows operating systems supported: Windows 11, Windows 10
Memory
Maximum internal memory: 256 GB
Memory slots type: DIMM
Supported memory types: DDR5 UDIMM
Number of memory slots: 4
Memory channels: Dual-channel
Weight & dimensions
Depth: 244 mm
Width: 244 mm
Network
Bluetooth: Yes
LAN controller: Dragon RTL8125BG
Wi-Fi: Yes
Ethernet LAN: Yes
Ethernet interface type: Gigabit Ethernet
Internal I/O
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
USB 2.0 connectors: 2
Number of SATA III connectors: 2
ATX Power connector (24-pin): Yes
Power fan connector: Yes
TPM connector: Yes
RGB LED pin header: Yes
CPU fan connector: Yes
BIOS
BIOS type: UEFI AMI
Storage controllers
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, SATA
RAID support: Yes
RAID levels: 0, 1, 10
Number of HDDs supported: 2
Rear panel I/O ports
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 4
DisplayPorts quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
HDMI ports quantity: 1
Expansion slots
PCI Express x16 (Gen 3.x) slots: 1
Number of M.2 (M) slots: 3
Number of M.2 (E) slots: 1
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x4 (Gen 3.x) slots: 1
Safety warning
Warnings: Dispose of in accordance with local regulations for electronic waste., Avoid contact with liquids to prevent electronic damage., Do not disassemble to avoid damage to internal components and loss of warranty.
