Technical details
Compliance certificates: Federal Communications Commission (FCC), CE
Processor
Processor socket: Socket AM5
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
Processor manufacturer: AMD
Graphics
On-board graphics card: Yes
Graphics card family: AMD
Graphics card: AMD RDNA 2
HDCP: Yes
Maximum resolution: 3840 x 2160 pixels
Parallel processing technology support: Not supported
High Dynamic Range (HDR) supported: Yes
HDCP version: 2.3
Features
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Cooling type: Passive
Product colour: Black
Audio chip: Realtek ALC897
Audio output channels: 7.1 channels
Motherboard form factor: micro ATX
Motherboard chipset family: AMD
Motherboard chipset: AMD A620
Memory
Memory channels: Dual-channel
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Number of memory slots: 2
Supported memory clock speeds: 8000
Maximum internal memory: 128 GB
Unbuffered memory: Yes
ECC сompatibility: ECC & Non-ECC
Weight & dimensions
Depth: 244 mm
Width: 244 mm
Network
Ethernet interface type: Fast Ethernet, Gigabit Ethernet, 2.5 Gigabit Ethernet
Ethernet LAN: Yes
Wi-Fi: No
Bluetooth: No
LAN controller: Dragon RTL8125BG
Internal I/O
Number of chassis fan connectors: 3
ATX Power connector (24-pin): Yes
CPU fan connector: Yes
TPM connector: Yes
Number of SATA III connectors: 4
Number of water pump connectors: 3
Front panel audio connector: Yes
Number of CPU fan connectors: 1
Number of RGB LED pin headers: 1
USB 2.0 connectors: 2
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
RGB LED pin header: Yes
12V power connector: Yes
Audio connector: Yes
BIOS
BIOS type: UEFI AMI
BIOS flashback button: Yes
Packaging content
Manual: Yes
Cables included: SATA
Screws included: Yes
Storage controllers
RAID levels: 0, 1, 10
Number of HDDs supported: 4
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, NVMe, SATA III
RAID support: Yes
Rear panel I/O ports
HDMI version: 2.1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
HDMI ports quantity: 1
Microphone in: Yes
USB 2.0 ports quantity: 2
DisplayPorts quantity: 1
Ethernet LAN (RJ-45) ports: 1
Rear speaker out: Yes
DisplayPort version: 1.4
Line-in: Yes
Expansion slots
Number of M.2 (M) slots: 2
PCI Express x1 (Gen 3.x) slots: 2
PCI Express x16 (Gen 4.x) slots: 1
Processor special features
Intel Extreme Memory Profile (XMP): Yes
AMD Extended Profiles for Overclocking (EXPO): Yes
