Processor
Maximum number of SMP processors: 1
Compatible processor series: AMD Ryzen 9000 Series, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series
Processor manufacturer: AMD
Processor socket: Socket AM5
Graphics
Graphics card family: AMD
On-board graphics card: Yes
HDCP version: 2.3
HDCP: Yes
Features
Audio output channels: 7.1 channels
Motherboard chipset family: AMD
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Motherboard form factor: micro ATX
Motherboard chipset: AMD A620A
Audio chip: Realtek ALC897
Memory
Supported memory types: DDR5-SDRAM
Number of memory slots: 2
Maximum internal memory: 128 GB
Memory slots type: DIMM
Memory channels: Dual-channel
ECC сompatibility: ECC & Non-ECC
Unbuffered memory: Yes
Weight & dimensions
Width: 244 mm
Depth: 226 mm
Network
Bluetooth: Yes
Wi-Fi standards: Wi-Fi 4 (802.11n), 802.11b, 802.11a, 802.11g, Wi-Fi 5 (802.11ac)
Bluetooth version: 5.0
LAN controller: Dragon RTL8125BG
Ethernet interface type: 2.5 Gigabit Ethernet
Top Wi-Fi standard: Wi-Fi 5 (802.11ac)
Ethernet LAN: Yes
Wi-Fi: Yes
Internal I/O
ATX Power connector (24-pin): Yes
Number of SATA III connectors: 4
CPU fan connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
EPS power connector (8-pin): Yes
Front panel audio connector: Yes
Number of chassis fan connectors: 3
TPM connector: Yes
Number of CPU fan connectors: 2
Number of water pump connectors: 1
RGB LED pin header: Yes
Number of RGB LED pin headers: 4
Number of EPS power connectors (8-pin): 1
USB 2.0 connectors: 2
BIOS
BIOS type: UEFI AMI
Packaging content
Cables included: SATA
Storage controllers
Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
DisplayPorts quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
Microphone in: Yes
Line-in: Yes
USB 2.0 ports quantity: 2
DisplayPort version: 1.4
Expansion slots
PCI Express x1 (Gen 3.x) slots: 2
Number of M.2 (M) slots: 2
PCI Express x16 (Gen 4.x) slots: 1
