Processor
Compatible processor series: AMD Ryzen™ 7, AMD Ryzen™ 3, 3rd Generation AMD Ryzen 5, 2nd Generation AMD Ryzen™ 7, 3rd Generation AMD Ryzen™ 9, AMD Ryzen™ 5, 3rd Generation AMD Ryzen™ 7, 2nd Generation AMD Ryzen™ 3, AMD Athlon, 3rd Generation AMD Ryzen™ 3, 2nd Generation AMD Ryzen™ 5
Processor socket: Socket AM4
Processor manufacturer: AMD
Processor thermal power (max): 105 W
Graphics
Maximum resolution: 4096 x 2160 pixels
DirectX version: 12.0
Graphics card family: AMD
Number of displays supported: 3
Features
Audio output channels: 7.1 channels
Motherboard chipset family: AMD
Audio chip: Realtek ALC892 / Realtek ALC897
Motherboard chipset: AMD B450
Motherboard form factor: ATX
Memory
Supported memory clock speeds: 2400, 2133 MHz, 2667, 2933
Maximum internal memory: 64 GB
Memory channels: Dual-channel
Number of memory slots: 4
Memory slots type: DIMM
Supported memory types: DDR4-SDRAM
Weight & dimensions
Width: 305 mm
Depth: 224 mm
Network
Ethernet interface type: Gigabit Ethernet
LAN controller: Realtek RTL8111H
Ethernet LAN: Yes
Wake-on-LAN ready: Yes
Internal I/O
TPM connector: Yes
USB 2.0 connectors: 2
ATX Power connector (24-pin): Yes
Number of SATA III connectors: 6
CPU fan connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Number of COM connectors: 1
12V power connector: Yes
Front panel audio connector: Yes
BIOS
BIOS type: UEFI AMI
Plug and Play: Yes
Packaging content
Cables included: SATA
Drivers included: Yes
Rear panel I/O ports
USB 2.0 ports quantity: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
DisplayPorts quantity: 1
VGA (D-Sub) ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
HDMI ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
PS/2 ports quantity: 1
Expansion slots
PCI Express x1 (Gen 2.x) slots: 4
PCI Express x16 (Gen 3.x) slots: 2
Other features
Quick installation guide: Yes
