Processor
Compatible processor series: AMD Ryzen 3000 Series, AMD Ryzen 5000 Series
Processor manufacturer: AMD
Maximum number of SMP processors: 1
Processor socket: Socket AM4
Graphics
Parallel processing technology support: Quad-GPU CrossFireX, CrossFireX
Maximum resolution: 4096 x 2160 pixels
DirectX version: 12.0
HDCP: Yes
Features
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Motherboard chipset family: AMD
Component for: PC
Motherboard form factor: ATX
Motherboard chipset: AMD B550
PC health monitoring: Temperature, Voltage, Fan, CPU
Audio chip: Realtek ALC897
Audio output channels: 7.1 channels
Memory
Memory channels: Dual-channel
Supported memory types: DDR4-SDRAM
Supported memory clock speeds: 4533 MHz, 3800, 4466, 3466, 4133, 2133 MHz, 4200, 4333, 4600, 2400, 2667, 3733, 4400, 4666, 2933, 3600, 4733, 3200, 4266, 4000, 4933, 3866
Memory slots type: DIMM
Number of memory slots: 4
Maximum internal memory: 128 GB
Unbuffered memory: Yes
ECC сompatibility: Non-ECC
Weight & dimensions
Width: 305 mm
Depth: 244 mm
Height: 330 mm
Network
LAN controller: Killer E3100G
Ethernet interface type: 2.5 Gigabit Ethernet
Wi-Fi: No
Wake-on-LAN ready: Yes
Ethernet LAN: Yes
Internal I/O
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
Front panel audio connector: Yes
Number of chassis fan connectors: 5
TPM connector: Yes
CPU fan connector: Yes
Number of SATA III connectors: 6
ATX Power connector (24-pin): Yes
RGB LED pin header: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
12V power connector: Yes
Thunderbolt headers: 1
USB 2.0 connectors: 3
BIOS
BIOS memory size: 256 Mbit
ACPI version: 5.1
BIOS type: UEFI AMI
System Management BIOS (SMBIOS) version: 2.3
Packaging content
Cables included: SATA
Drivers included: Yes
Storage controllers
RAID levels: 1, 10, 0
RAID support: Yes
Supported storage drive interfaces: M.2, SATA III
Supported storage drive types: HDD & SSD
Rear panel I/O ports
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 6
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
PS/2 ports quantity: 1
Digital audio optical out: 1
USB 2.0 ports quantity: 2
HDMI version: 2.1
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
S/PDIF out port: Yes
Expansion slots
PCI Express x1 (Gen 3.x) slots: 1
Number of M.2 (M) slots: 2
PCI Express x16 slots: 3
Other features
Weight: 465 g
Logistics data
Harmonized System (HS) code: 84733020
